The parts for PE-3402B-A
Switch PWB(B2) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C901 043-1802-90 0.01uF D914 001-7088-92 HSMF-A355- Q904 125-2027-95 DTC143ZU
C902 043-1804-90 0.1uF G33J1 Q905 193-1781-50 2SC3440
C903 043-1804-90 0.1uF D915 001-7088-92 HSMF-A355- Q906 193-1781-50 2SC3440
C904 043-1804-90 0.1uF G33J1 R903 119-4711-15 1/10W 470 ohm
C905 043-1804-90 0.1uF D916 001-7088-92 HSMF-A355- R904 119-2211-15 1/10W 220 ohm
C906 043-1804-90 0.1uF D918 001-2601-90 MA728 R905 119-1241-15 1/10W 120k ohm
C907 043-1804-90 0.1uF D919 001-1323-90 L1SS355T1G R906 119-4721-15 1/10W 4.7k ohm
C908 043-0603-90 16V 10uF D931 001-0584-21 MA8062 R907 119-1021-15 1/10W 1k ohm
C909 043-0603-90 16V 10uF D934 001-7062-90
RBR1111C
R908 119-2711-15 1/10W 270 ohm
C910 043-0603-90 16V 10uF IC901 051-6089-00 NJU6539 R910 119-1021-15 1/10W 1k ohm
C911 043-1808-90 1200pF IR901 060-4021-00 GPIUX51 R911 119-1041-15 1/10W 100k ohm
C912 043-1808-90 1200
F J702 075-9021-50 YW1310E431 R912 119-1031-15 1/10W 10k ohm
C914 043-1804-90 0.1uF J901 074-3014-72 22P R913 119-1031-15 1/10W 10k ohm
D909 001-4301-43 HZU8.2B1 J904 074-4036-50 4P
PE-3402B-A R914 119-3921-15 1/10W 3.9k ohm
D910 001-4301-29 HZU5.1B2 /PE-3402K-B) R915 119-1011-15 1/10W 100 ohm
D911 001-7088-92 HSMF-A355- LCD901 379-1457-51
INDICATOR R924 119-3311-15 1/10W 330 ohm
G33J1 LCD
R925 119-1031-15 1/10W 10k ohm
D912 001-7088-92 HSMF-A355- P903 076-0478-52 2P R926 119-3311-15 1/10W 330 ohm
G33J1 P904 076-0502-55 5P
PE-3402B-A R927 119-1031-15 1/10W 10k ohm
D913 001-7088-92 HSMF-A355- /PE-3402K-B) R928 119-3311-15 1/10W 330 ohm
G33J1 Q903 193-1781-50 2SC3440 R929 119-1031-15 1/10W 10k ohm
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C233 043-1608-90 0.1uF IC204 051-7538-90
SN74LVC3G17DCTR
R252 032-0140-63
1/10W 27k ohm F
C234 043-1841-90 0.047uF IC205 051-3060-90 AZ4558M R253 032-0140-63
1/10W 27k ohm F
C235 043-1841-90 0.047uF IC206 051-3060-90 AZ4558M R254 032-0140-89
1/10W 47k ohm F
C236 187-1063-35 16V 10uF IC304 051-3060-90 AZ4558M R255 032-0140-89
1/10W 47k ohm F
C237 187-1063-35 16V 10uF IC305 051-3060-90 AZ4558M R256 032-0140-63
1/10W 27k ohm F
C238 187-1063-35 16V 10uF IC306 051-3060-90 AZ4558M R257 032-0140-63
1/10W 27k ohm F
C239 187-1063-35 16V 10uF IC401 051-3605-90 NJM2360AM R258 119-1011-15 1/10W 100 ohm
C240 187-1063-35 16V 10uF L401 010-2285-56
2.25k ohm/100MHz
R259 119-1011-15 1/10W 100 ohm
C241 187-1063-35 16V 10uF L402 010-2285-56
2.25k ohm/100MHz
R261 119-4731-15 1/10W 47k ohm
C242 187-1063-35 16V 10uF L403 010-6003-03 270uH R262 119-1031-15 1/10W 10k ohm
C243 187-1063-35 16V 10uF L404 010-3406-66 22uH J R263 119-0000-05
1/10W 0 ohm JW
C244 189-1083-32 16V 1000uF Q201 125-2027-95 DTC143ZU R264 119-1031-15 1/10W 10k ohm
C245 165-1073-35 16V 100uF Q202 191-1197-50 2SB1197K Q
R R265 119-1031-15 1/10W 10k ohm
C306 187-1053-65 50V 1uF Q203 125-4024-90 3DG3875 R266 119-4721-15 1/10W 4.7k ohm
C307 187-1053-65 50V 1uF Q204 125-4024-90 3DG3875 R267 119-1531-15 1/10W 15k ohm
C312 187-1053-65 50V 1uF Q205 125-2027-92 DTC124EUA R268 119-1021-15 1/10W 1k ohm
C313 187-1053-65 50V 1uF Q206 125-3005-90 KTA1273 R270 116-1521-15 1/4W 1.5k ohm
C348 043-0540-00 6.3V 10uF Q407 125-4012-90 KTD1304 R271 116-1521-15 1/4W 1.5k ohm
C349 043-0540-00 6.3V 10uF Q408 125-4012-90 KTD1304 R281 119-1031-15 1/10W 10k ohm
C350 043-0540-00 6.3V 10uF R218 119-3321-15 1/10W 3.3k ohm R340 033-1041-15 1/10W 100k ohm
C351 043-0540-00 6.3V 10uF R219 119-1031-15 1/10W 10k ohm R341 033-1041-15 1/10W 100k ohm
C352 043-0540-00 6.3V 10uF R220 119-1821-15 1/10W 1.8k ohm R342 033-1041-15 1/10W 100k ohm
C353 043-0540-00 6.3V 10uF R221 119-4731-15 1/10W 47k ohm R343 033-1041-15 1/10W 100k ohm
C354 045-1011-50 100
F CH R224 119-1011-15 1/10W 100 ohm R344 033-1041-15 1/10W 100k ohm
C355 045-1011-50 100
F CH R225 119-1021-15 1/10W 1k ohm R345 033-1041-15 1/10W 100k ohm
C356 045-1011-50 100
F CH R226 119-1021-15 1/10W 1k ohm R346 033-1031-15 1/10W 10k ohm
C357 045-1011-50 100
F CH R227 119-1031-15 1/10W 10k ohm R347 033-1031-15 1/10W 10k ohm
C358 045-1011-50 100pF CH R228 119-1031-15 1/10W 10k ohm R348 033-1031-15 1/10W 10k ohm
C359 045-1011-50 100
F CH R230 119-0000-05
1/10W 0 ohm JW
R349 033-1031-15 1/10W 10k ohm
C401 042-1631-50 10V 100uF R231 119-0000-05
1/10W 0 ohm JW
R350 033-1031-15 1/10W 10k ohm
C402 168-1042-78 16V 0.1uF R234 119-6831-15 1/10W 68k ohm R351 033-1031-15 1/10W 10k ohm
C403 166-2211-50 220pF CH R236 119-1041-15
1/10W 100k ohm
R352 033-1031-15 1/10W 10k ohm
C404 168-2232-55 0.022uF K R237 119-1041-15
1/10W 100k ohm
R353 033-1031-15 1/10W 10k ohm
C405 187-1063-35 16V 10uF R238 119-1021-15 1/10W 1k ohm R354 033-1031-15 1/10W 10k ohm
C406 042-1452-81 10V 220uF R239 119-1041-15
1/10W 100k ohm
R355 033-1031-15 1/10W 10k ohm
C407 168-1042-78 16V 0.1uF R240 119-1021-15 1/10W 1k ohm R356 033-1031-15 1/10W 10k ohm
C408 042-1631-50 10V 100uF R241 119-1041-15
1/10W 100k ohm
R357 033-1031-15 1/10W 10k ohm
C414 187-1063-35 16V 10uF R242 032-0140-89 1/10W 47k ohm F R401 119-2291-15 1/10W 2.2 ohm
C416 187-1063-35 16V 10uF R243 032-0140-89 1/10W 47k ohm F R402 119-2291-15 1/10W 2.2 ohm
D200 001-4301-29 HZU 5.1B2 R244 032-0140-89 1/10W 47k ohm F R403 119-1531-15 1/10W 15k ohm
D201 001-4301-29 HZU 5.1B2 R245 032-0140-89 1/10W 47k ohm F R405 119-2721-15 1/10W 2.7k ohm
D202 001-1310-00 KDS160-RTK R246 032-0140-89 1/10W 47k ohm F R410 116-3911-15 1/4W 390 ohm
D301 001-4301-29 HZU 5.1B2 R247 032-0140-89 1/10W 47k ohm F R413 119-2231-15 1/10W 22k ohm
D304 001-4301-29 HZU 5.1B2 R248 032-0140-89 1/10W 47k ohm F R414 119-2231-15 1/10W 22k ohm
D402 001-2606-90 M1FS4 R249 032-0140-89 1/10W 47k ohm F R419 119-3311-15 1/10W 330 ohm
F301 060-0108-90
1/6ZP 0 ohm JW
R250 032-0140-89 1/10W 47k ohm F R423 119-3311-15 1/10W 330 ohm
F302 060-8056-93
CCP2E20HTTE
R251 032-0140-89 1/10W 47k ohm F R425 119-1021-15 1/10W 1k ohm
-12-
CX501/CX501B/CX501A
