Clarion PX-4226A-A User Manual

67
English
20. SPECIFICATIONS
Declaration of conformity
We declare that this model PE-4230A-A is following
the provision of Directive 1999/5/EC&2011/65/EU with
the essential requirements and the other relevant regula-
tions.
FM tuner
Frequency Range : 87.50 ~ 108.00 MHz
Usable Sensitivity : <18dB
Stereo Separation (1 kHz) : >18dB
Frequency Response (±3dB) : 100Hz: 0 ±3dB, 7kHz :-10 ± 3dB
AM tuner
Frequency Range : 531 ~ 1629 kHz
Usable Sensitivity : <34dB
USB Port
Specification : USB 2.0
File system : FAT16, FAT32
Playable audio format : MP3 (.mp3), WMA (.wma),
AAC (.m4a), WAV (.wav)
Playable video format : MPEG (.mpg, .mpeg),
MPEG-4 (.mp4)
H.264 (.mkv,.avi)
WMV7/8/9 (.wmv)
Maximum current (USB 1) : 1.5A
(USB 2) : 500mA
Supported iPhone/iPod:
iPhone 7 Plus , iPhone 7, iPhone SE,
iPhone 6S Plus, iPhone 6S,
iPhone 6 Plus, iPhone 6,
iPhone 5S, iPhone 5C, iPhone 5,
iPod Touch 6th Gen
Supported Android OS versions
Android OS 5 and above
For further details on smartphone compatibility, please visit:
http://clarion.com.my/iop-compatibility
Screen
Screen size : 7 inch
Resolution : 800 (horizontal) x 480 (vertical)
x 3 (RGB)
Touch type : TFT Active Matrix Display
Bluetooth® Wireless Technology
Version : Bluetooth® 4.1
Frequency Range : 2.40 ~ 2.4835 GHz, ISM band
RF Power : Class 2 (2.5 mW)
Profiles : HFP 1.6, A2DP 1.3, AVRCP 1.5,
PBAP 1.2
Operating Temperature : -20°C ~ +60°C
Telephone Operation : Noise reduction, echo cancellation,
full duplex telephony, wideband
speech
General
Power Source Voltage : 10.8 V ~ 15.6 V
Current Consumption : Less than 15A
Weight of the Main Unit : 1.437kg
Dimensions of the Main Unit : 203.0 mm Width X
104.0 mm Height X
123.3 mm Depth
Maximum Power Output : 180 W (45 W x 4ch)
Operating Temperature : -20ºC ~ +70ºC
