If a monitor is installed in the rear zone and connected
to the rear zone AV output, passengers in the back
seat can watch the DVD/iPod Video/AUX1/ AUX2
video separately from front source.
1. Touch the button to access the front source.
2. Touch the button to close the rear source.
Multi-Zone Operation
Independent sources can be played simultaneously
on the unit. For example, a FM/AM console can be
playback on the front screen while DVD video is
available to rear passengers. But now can’t select
DVD video in front.
Access Rear-Zone
1. Touch the Rear button on Main Menu to access the
Rear Source.
2. Select a source to play.
Exit Rear-Zone
Touch the 2-Zone off button to close the Rear
Source.
Note:
1. If the source is selected as the front, the source in
rear can’t be selected.
2. If the source is selected as the rear, the source in
front can’t be selected.
3. Touch the Front button to access the main menu but
not close the Rear Source.
DVD Video in Rear
1 -Option button
2 -Show Cursor keys
3 -Previous Chapter /Fast Backward button
4 -Play/Pause button
5 -Next Chapter /Fast Forward button
6 -Elapsed playing time
7 -Menu List button
8 -Front/Rear button
If the screen displays Rear Source, touch Front/Rear
button to switch to Front Source.
If the screen displays Front Source, touch Front/Rear
button to switch to Rear Source.
DVD Video Rear Source Control Info
Mode
Touch BACK button to return.
DVD Video Rear Source Control Direct
Mode
NOTE: More detail please refer to DVD Video Front
source.
19. REAR SOURCE OPERATIONS
12
8
1 2 3 4 5 6 7
