Clevo P870KM Service Manual

Introduction
Overview 1 - 3
1.Introduction
Storage
Two changeable 2.5" (6cm) 7.0mm (h)/ 9.5mm (h) SATA
(Serial) Hard Disk Drives/Solid State Drives (SSD) support-
ing RAID level 0/1
(Factory Option) Two M.2 SATA 2280 SSDs supporting
RAID level 0/1
Or
(Factory Option) Three M.2 PCIe Gen3 x4 2280 SSDs sup-
porting RAID level 0/1
Security
Security (Kensington® Type) Lock Slot
BIOS Password
Fingerprint Reader Module
Trusted Platform Module 2.0
Intel PTT for Systems Without TPM Hardware
Interface
Five USB 3.0 (USB 3.1 Gen 1) Ports (Including one AC/DC
Powered USB port)
Two USB 3.1 Gen 2 Ports (Type C)
Two Mini DisplayPorts (1.3)
One HDMI-Out Port
One 2-In-1 Audio Jack (Headphone/ S/PDIF Optical Output
Combo Jack)
One Microphone-In Jack
One Line-Out Jack
One Line-In Jack
Two RJ-45 LAN Jacks
One DC-In Jack
M.2 Slots
Slot 1 for Combo WLAN and Bluetooth Module
Slot 2 for SATA or PCIe Gen3 x4 SSD
Slot 3 for SATA or PCIe Gen3 x4 SSD
Slot 4 for PCIe Gen3 x4 SSD
Communication
Built-In Qualcomm 10/100/1000Mb Base-TX Ethernet LAN
2.0M FHD PC Camera Module
WLAN/ Bluetooth M.2 Modules:
(Factory Option) Intel® Dual Band Wireless-AC 8265 Wire-
less LAN (802.11ac) + Bluetooth 4.1
(Factory Option) Intel® Dual band Wireless-AC 3168 Wire-
less LAN (802.11ac) + Bluetooth 4.0
(Factory Option) Qualcomm® Atheros Killer™ Wireless-AC
1535 Wireless LAN (802.11ac) + Bluetooth 4.1
(Factory Option) Wireless LAN (802.11ad) + Bluetooth 4.1
combo
Card Reader
Embedded Multi-In-1 Push-Push Card Reader
MMC (MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD / SDHC/ SDXC (up to UHS-
II)
Features
Supports NVIDIA® G-SYNC™ Technology
(G-SYNC is only supported if you have a G-SYNC capable
display and a GTX series video adapter)
Virtual Reality Ready
Power
Embedded 8-cell Smart Lithium-Ion Battery Pack, 89WH
Dual Full Range AC/DC Adapters with the Power Converter
Box
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 19.5V, 11.8A (230W)
Environmental Spec
Temperature
Operating: 10°C - 35°C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Dimensions & Weight
428mm (w) * 308mm (d) * 47.2mm (h)
4.8kg (
Barebone System with 1 Video Card and 89WH Bat-
tery)

Power Converter
You must use the power converter
supplied with the dual AC/DC adapt-
ers connected to power this comput-
er. Do not use a single AC/DC
adapter to power the system.

Clevo P870KM Specifications

General

Brand	Clevo
Model	P870KM
Category	Laptop
Language	English
