Clevo P870KM Service Manual

Disassembly
Removing the Battery 2 - 5
2.Disassembly
Removing the Battery
1. Turn the computer off, and turn it over.
2. Remove the screws - (Figure 1a).
3. Carefully lift the bottom case
up in the direction of the arrow and remove it (Figure 1b).
4. The battery will be visible at point on the computer (Figure 1c
).
1
9
10
11
12
Figure 1
Battery Removal
a. Remove the screws.
b. Remove the bottom case.
c. Locate the battery.
2
a.
b.
3
4
5
10
12
6
7
9
c.
10
1
8
11

10. Bottom Case
•9 Screws
