Disassembly
Wireless LAN, Combo Module Cables 2 - 21
2.Disassembly
Wireless LAN, Combo Module Cables
Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, WiGig modules are not la-
belled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for identification
as outlined in the table below.
Cable 1 is usually connected to antenna 1 (Main) on the module, and cable 2 to antenna 2 (Aux).
Module Type
Antenna
Type
Cable Color
Cable Cover
Type
WLAN/WLAN & Bluetooth
Combo
WM 1 Black
TransparentWM 2 Gray
WM 3 White
WiGig
WM 1 Blue White
WM 2 Black
Transparent
WM 3 Black
