Introduction
1 - 2 Specifications
1.Introduction
Specifications
Latest Specification Information
The specifications listed here are correct at the
time of sending them to the press. Certain items
(particularly processor types/speeds) may be
changed, delayed or updated due to the manu-
facturer's release schedule. Check with your
service center for more details.
CPU
The CPU is not a user serviceable part. Ac-
cessing the CPU in any way may violate your
warranty.
Processor Options
Intel® Core™ i7 Processor
i7-7500U (2.70GHz)
4MB Smart Cache, DDR3L-1867MHz, TDP 15W
Intel® Core™ i5 Processor
i5-7200U (2.50GHz)
4MB Smart Cache, DDR3L-1867MHz, TDP 15W
Intel® Core™ i3 Processor
i3-7100U (2.40GHz)
4MB
Smart Cache, DDR3L-1867MHz, TDP 15W
BIOS
64Mb SPI Flash ROM
AMI BIOS
Memory
Two 204 Pin SO-DIMM Sockets Supporting DDR3L 1600/
1866MHz Memory
Memory Expandable up to 16GB
Compatible with 2GB, 4GB or 8GB Modules
(The real memory operating frequency depends on the FSB
of the processor.)
LCD Options
15.6" (39.62cm), 16:9, HD (1366x768)/FHD (1920x1080)
(Thickness: 3.8mm)
Video Adapter
Intel HD Graphics
Dynamic Frequency
Intel Dynamic Video Memory Technology
Microsoft DirectX®12 Compatible
Audio
High Definition Audio Compliant Interface
2 * Built-In Speakers
Built-In Microphone
(Factory Option) Built-In Array Microphone
Security
Security (Kensington® Type) Lock Slot
BIOS Password
Intel PTT
(Factory Option) TPM 2.0
Storage
One Changeable 2.5" 7mm (h) SATA HDD/SSD
(Factory Option) One 9.5mm(h) Optical Device Type Drive
(Super Multi Drive)
Or
(Factory Option) Dummy ODD or 7mm 2nd HDD/SSD
caddy
(Factory Option) One M.2 SATA/PCIe Gen2 x2 Solid State
Drive (SSD)
(Processor Dependent)
Pointing Device
Built-in Touchpad
Keyboard
Full-size “WinKey” keyboard (with numeric keypad)
M.2 Slots
Slot 1 for WLAN and Bluetooth Combo Module
Slot 2 for SATA/PCIe Gen2 x2 SSD
(Factory Option) Slot 3 for 3G/4G Module
