Clevo W950BU User Manual

Disassembly
Removing the System Memory (RAM) 2 - 11
2.Disassembly
Removing the System Memory (RAM)
Figure 7
RAM Module
Removal
a. The RAM modules will
be visible at point
on the mainboard.
b. Pull the release lat-
ches.
c. Remove the module.

Contact Warning
Be careful not to touch
the metal pins on the
module’s connecting
edge. Even the cleanest
hands have oils which
can attract particles, and
degrade the module’s
performance.
1
The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting
DDR3L Up to 1066/1333 MHz. The main memory can be expanded up to 8GB. The SO-DIMM modules supported are
1024MB and 2048MB DDR3L Modules. The total memory size is automatically detected by the POST routine once you
turn on your computer.
Memory Upgrade Process

4. RAM Module
1. Turn off the computer, turn it over to remove the battery (page 2 - 5) and bottom cover (page 2 - 6).
2. The RAM modules will be visible at point on the mainboard (Figure 7b
).
3. Gently pull the two release latches ( & ) on the sides of the memory socket in the direction indicated by the
arrows (Figure 7b).
The RAM module will pop-up (Figure 7c), and you can then remove it.
1
2
3
4
a.
1
c.
b.
2 3
4

Single Memory Module
Installation
If your computer has a single
memory module, then insert
the module into the Channel
0 (JDIMM1 / RAM1) socket.
In this case this is the hori-
zontal memory socket.
