Technical data
7 TECHNICAL DATA
Technical features (SINGLESplit)
Unit 27M 35M 53M 70M
Refrigerant piping
Liquid line
inch Ø 1/4” Ø 1/4” Ø 1/4” Ø 3/8”
mm Ø 6.35 Ø 6.35 Ø 6.35 Ø 9.52
Gas line
inch Ø 3/8” Ø 3/8” Ø 1/2” Ø 5/8”
mm Ø 9.52 Ø 9.52 Ø 12.7 Ø 15.9
Max equivalent length m 25 25 30 50
Max. height dierence outdoor unit / indoor unit m ±10 ±10 ±20 ±25
Refrigerant pre-charge kg/m 0.55 / 5 0.55 / 5 1.1 / 5 1.45 / 5
GWP tco 675 675 675 675
Tons of equivalent CO tt 0.37 0.37 0.74 0.98
Additional refrigerant charge g/m 12 12 12 24
Unit 27M 35M 53M 70M
Electrical connections
Main power supply (outdoor unit)
V / Hz / p 230 / 50 / 1
n° cables / cross
section
2 x 2.5mm
2
+ G
Outdoor unit
--> indoor unit
connection
Signal
n° cables / cross
section
2 x 1.5mm
2
2 x 1.5mm
2
2 x 1.5mm
2
2 x 2.5mm
2
Power supply
n° cables / cross
section
2 x 1.5mm
2
+ G 2 x 1.5mm
2
+ G 2 x 1.5mm
2
+ G 2 x 2.5mm
2
+ G
Power consumption (outdoor unit + indoor unit) 27M 35M 53M 70M
Rated power
input
Cooling
Nominal
(Min~Max)
W
740
(80~1.100)
1.140
(120~1.650)
1.550
(560~2.050)
2.510
(420~3.200)
Heating
Nominal
(Min~Max)
W
780
(70~990)
1.080
(110~1.480)
1.500
(780~2.000)
2.130
(300~3.100)
Rated current
input
Cooling
Nominal
(Min~Max)
A
4.95
(0.35~4.78)
5.10
(0.5~7.2)
6.7 (2.4~9.0)
10.9
(1.8~13.9)
Heating
Nominal
(Min~Max)
A
3.50
(0.32~4.32)
4.80
(0.5~6.4)
6.5 (3.4~8.7)
9.46
(1.4~14.4)
NOTE:
– at max. pipe length, the yield is approximately 90%
– with a height dierence >5m it is advisable to insert a siphon.
