InteliLite
NT
– MRS10/11/15/16, SW version 1.5, ©ComAp – September 2009 15
IL-NT-MRS-1.5-Reference Guide.pdf
Hint:
Please see chapter IL-NT BIO8 interface (optional card) for technical details.
IL-NT RD Remote display software
IL-NT RD is remote display software for a controller. Remote display provides the same control and
monitoring functions as controller itself. Remote display for IL-NT controllers uses standard IL-NT
controller with Remote display software. No further programing of the display is required – unit is self
configurable from the main controller. It is connected with the controller via IL-NT-RS232
communication modules using RS232 line. Longer distances (up to 1200m) are possible using IL-NT-
RS232-485 communication module or when RS232/RS485 converters are used.
The IL-NT RD hardware type should fit to the master IL-NT.
Hint:
Please see the IL-NT-RD Remote display software chapter for more details.
Remote announciator IGL - RA15
The remote announciator IGL-RA15 can be connected to the IL-NT unit via CAN bus. Any of the
binary outputs can be configured (using LiteEdit software) to each LED diode on the RA15. The
module can be also enabled or disabled using LiteEdit software.
If IGL-RA15 remote announciator is not communicating with a controller via CAN bus, it activates a
warning.
See the documentation of RA15 for the technical and function description.
