Compac CNG Installation And Service Manual

Technical Specifications
Specifications
Compac Industries Ltd.
Page 50
www.compacngv.com
Specifications
Technical Specifications
Compac CNG Loading Posts (excluding hose assembly) are designed to
operate within the atmospheric environment. Gas parameters are outlined
below.
They require the following operating conditions:
Air temperature range
- 25 °C to + 55 °C
Air humidity range
10% to 95%
Gas type
High pressure natural gas (CNG)
Gas temperatures
- 40 °C to + 80 °C (continuous)
- 55 °C to + 80 °C (intermittent)
Maximum Water Dew Point
- 32 °C at 250 bar
Maximum Working Pressure
(Inlet)
275 bar (350 bar option)
Power Requirements
230V +/-10%, 50Hz, 2A
Specific Specifications
Standard Model
Flow
(The maximum flow rate is not only
determined by the type of loading
post but also depends on the size of
the refuelling hose, the model of the
breakaway, the type of refuelling
nozzle, and the vehicle coupling.)
1 – 15 kg /min
Pressure rating
(350 bar options utilise air actuated
valves and require a compressed air
supply.)
275 bar
(350 bar option)
Accuracy
+/- 1.0%
Meter
Compac KG80 coriolis mass flow
Internal Pipework
1/2”
Hose
3/8”
In-line breakaways
Various available
Refuelling valve
NGV1 or NZ 7/16" probe
Loading meter overall dimensions
L x W x H
400 mm x 400 mm x 2440 mm
Minimum flow cut-off
0.5 -10 kg/min (settable)
Maximum flow cut-off
10 - 99 kg/min (settable)
