Creality Sermoon V1 User Manual

0110
1. PLA mode: As our company recommends the PLA mode, the system’s parameters have
been set according to PLA f ilaments. It is recommended to use Creality f ilaments for printing.
When the inside the box temperature exceeds 30°C, please open the top cover to avoid
nozzle blockage.
2. ABS mode: As our company recommends the ABS mode, the system’s parameters have been
set according to ABS f ilaments. It is recommended to use Creality f ilaments for printing. When
printing, please ensure that the top cover is on to keep the device’s temperature inside.
Note: When printing with ABS f ilaments, it is recommended that the size of a single
model be controlled within 100 x 100 mm (length x width) to avoid warping caused by
the characteristics of the f ilaments, which can result in printing failure.
Note: Please install the f ilaments as shown in the
f igure above.
2.2.3 Printing modes
225 225
100 70.68
69 70
100 70.68
69 70
225 225
225 225
100 70.68
69 70 225 225
100 70.68
69 70

Creality Sermoon V1 Specifications

General

Build Volume	175 x 175 x 165 mm
Layer Resolution	0.1-0.4 mm
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Connectivity	Wi-Fi, USB
Display	4.3-inch Touch Screen
Leveling	Automatic leveling
Frame Material	Metal
Printing Technology	FDM
Heated Bed	Yes
Bed Temperature	Up to 80°C
Nozzle Temperature	Up to 250°C
Machine Dimensions	400 x 380 x 430 mm
Machine Weight	11.5 kg
Supported Filaments	PLA, ABS, TPU
Extruder Type	Single Extruder
