Cub Cadet 7304 Parts Manual

-7-
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 IM-326021860 Housing Assembly, Axle ..............
Includes Ref. No. 2
1
2 IM-030500820 Pin, Dowel ................................... 4
3 IM-326345040 Housing, Axle LH ........................ 1
4 IM-398400440 Gauge, Oil Level .......................... 1
5 IM-322013110 Housing Assembly, Pinion Gear ..
Includes Ref. No. 2
2
6 IM-052300400 O-Ring ......................................... 2
7 IM-040136204 Bearing, Ball ................................ 2
8 IM-040106303 Bearing, Ball ................................ 2
9 IM-036500047 Ring, Snap ................................... 2
10 IM-326240290 Gear, Final Pinion Idler ................ 4
11 IM-322511091 Shaft, Idler Drive .......................... 2
12 IM-052300650 O-Ring ......................................... 2
13 IM-322117840 Housing, Final Drive LH .............. 1
14 IM-322117850 Housing, Final Drive RH .............. 1
15 IM-326240280 Gear, Final Drive Pinion .............. 2
16 IM-042532006 Bearing, Tapered ......................... 2
17 IM-040106006 Bearing, Ball ................................ 2
18 IM-050600038 Seal, Oil ....................................... 2
19 IM-064600016 Plug ............................................. 2
20 IM-025100016 Washer, Seal ............................... 2
21 IM-025100012 Washer, Seal ............................... 3
22 IM-322212311 Housing, Final Drive .................... 2
23 IM-326312330 Wheel Hub/Shaft ......................... 2
24 IM-326370450 Gear, Final Drive ......................... 2
25 IM-050609043 Seal, Oil, 35mm x 55mm x 15mm 2
26 IM-040106205 Bearing, Ball ................................ 2
27 IM-040106206 Bearing, Ball ................................ 2
28 IM-036100030 Ring, Snap ................................... 2
29 IM-330310712 Kingpin ........................................ 2
30 IM-334525190 Arm, Steering LH ......................... 1
31 IM-334525200 Arm, Steering RH ........................ 1
32 IM-011511025 Bolt, M10 x 25 ............................. 12
33 IM-011511030 Bolt, M10 x 30 ............................. 4
34 IM-011510820 Bolt, M8 x 20 ............................... 12
35 IM-011510825 Bolt, M8 x 25 ............................... 8
36 IM-010311035 Bolt, M10 x 35 ............................. 2
37 IM-010301212 Bolt, M12 x 12 ............................. 3
38 IM-020900008 Nut, M8 ........................................ 2
39 IM-399234470 Collar ........................................... 2
40 IM-010310825 Bolt, M8 x 25 ............................... 2
41 IM-334712010 Rod, Tie ....................................... 1
42 IM-334801170 Tie Rod End, LH ..........................
Includes Ref. Nos. 44 thru 46
1
44 IM-334810207 Cover, Dust ................................. 2
45 IM-334810209 Nut, Castle, M12 x 1.25 ............... 2
46 IM-030103025 Pin,Cotter .................................... 2
47 IM-334801150 Tie Rod End, RH .........................
Includes Ref. Nos. 44 thru 46
1
48 IM-020109029 Nut, Jam, LH Thrd ....................... 1
49 IM-020800014 Nut, Jam, M14 RH Thrd .............. 1
50 IM-025100020 Washer, Seal ............................... 1
51 IM-040106304 Bearing, Ball ................................ 2
52 IM-199280540 Shim, 0.2T ................................... AR
53 IM-199280550 Shim, 0.5T ................................... AR
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
4WD AXLE ASSEMBLY
