Culligan E2 Plus Series User Manual

Series E2 Plus International 39
Cat. No. 01023094
Appendix A Series E2 Plus International
E2 Plus International Specifications
Model
Part Number
E2 Plus-2 E2 Plus-3 E2 Plus-4 E2 Plus-5 E2 Plus-6
01023850 01023851 01023852 01023853 01023854
Nominal Capacity, GPD* 3360 4870 6300 7560 8400
Dimensions, Series E2 Plus Units
Width - in [mm] 25.8 [655.3]
Depth - in [mm] 29.3 [744.2]
Height - in [mm] 52.6 [1336]
Operating Weight lb [kg] 198 [89.1] 228 [102.6] 258 [116.1] 288 [129.6] 318 [143.1]
Unit Connections
Inlet (NPT) 3/4 NPT
Product (Tube) 1/2 NPT
Concentrate (Tube) 0.5"
Electrical
Motor Horsepower (hp) 1.0
Power Requirement (VAC/Hz/phase) 220/50/1
Full Load Current (amp) 9.4
Hydraulic - Prefilter
Housing Quantity 2 3 4 5 6
Cartridge Quantity 1
Cartridge Size - in [mm] 10 [254]
Cartridge Rating (micron) 5
Hydraulic - RO
RO Housing Quantity 2 3 4 5 6
RO Element Quantity 2 3 4 5 6
RO Element Length - in [mm] 40 [1016] 40 [1016] 40 [1016] 40 [1016] 40 [1016]
Product Flow - gpm [L/min]* 2.34 [8.84] 3.39 [12.81] 4.38 [16.56] 5.25 [19.87] 5.83 [22.08]
Concentrate Flow - gpm [L/min]* 2.34 [8.84] 2.26 [8.53] 2.91 [11.04] 1.75 [6.63] 1.94 [7.36]
Recovery (%)*
Design 50 60 60 75 75
Minimum 40 50 50 60 60
Maximum Module Feed Pressure psig [kPa] 160 [1103]
Nominal Module Feed Pressure psig [kPa] 140 [965]
Maximum Product Pressure psig [kPa] 40 [276]
Operating Temperature °F [°C] 40–100 [4–38]
Inlet Pressure
Minimum, dynamic psig [kPa] 20 [103]
Maximum, dynamic psig [kPa] 40 [276]
Maximum, static psig [kPa] 100 [689]
Required Inlet Feed Flow gpm [L/min] 4.67 [17.6] 5.64 [21.33] 7.29 [27.64] 7.00 [26.46] 7.78 [29.48]
Pump Flow @ 125 psi gpm [Lmin] 9.24 [34.94] 11.0 [41.6] 11.0 [41.6] 11.0 [41.6] 11.0 [41.6]
Salt Rejection, Nominal (%) 97 97 97 96 95
†Calculated using a 0.85 fouling factor
*Nominal capacity based on new RO membranes operating on a properly pretreated feed water of 500 ppm TDS as NaCl,
77 °F (25 °C), Silt Density Index (SDI) below 3, and supplying water to atmosphere. Productivity will vary depending on
the actual feed water quality and temperature.
