3. SPECIFICATION
3.1 Accessories
No DESCRIPTION Q’TY
1 TENS stimulator device 1 piece
2 Electrodes Leads 2 pieces
3 40mm x 40mm adhesive electrodes 4 pieces
4 9V Alkaline Battery, type 6LR61 1 piece
5 Instruction Manual 1 piece
6 Carrying case 1 piece
3.2 Technical Information
Channel Dual, isolated between channels
Power supply
9.0 V Alkaline battery, type: 6LR61
Adapter output:9.0Vdc, 800mA (optional)
Operating
conditions
5°C to 40°C （41℉H to 104℉H）with a
relative humidity of 30%-75%,atmospheric
pressure from 700 to 1060 Hpa
Storage
conditions
-10°C to 50°C （14℉H to 122℉H）with a
relative humidity of 10%-90%,atmospheric
pressure from 700 to 1060 Hpa
Dimensions
4.5×2.55×0.9 inches(L*W*H)
Weight
0.28 lbs(With battery)
Tolerance
There may be a ±5% tolerance of all setting
and ±10% tolerance of output of intensity.
Electrode
Detection
Function
The amplitude level will be reset to 0mA
when the amplitude level is 12mA or
greater and an open circuit at either
channel is detected.
Timer
15,30,60 minutes and continuous
13
