D-Link AC1200 User Manual

DIR-842V2 AC1200 Wi-Fi Gigabit Router
User Manual
Configuring via Web-based Interface
Page 45
CHAPTER 4. CONFIGURING VIA WEB-BASED
INTERFACE
Setup Wizard
To start the Setup Wizard, go to the Settings / Setup Wizard section. On the opened page, click
the OK button and wait until the factory default settings are restored.
Figure 31. Restoring the default settings in the Wizard.
If you perform initial configuration of the router via Wi-Fi connection, please make sure that you
are connected to the wireless network of DIR-842V2 (see the WLAN name (SSID) on the
barcode label on the bottom panel of the device) and click the NEXT button.
Figure 32. Checking connection to the wireless network.
Click the START button.
Figure 33. Starting the Wizard.

D-Link AC1200 Specifications

General

Interface	WLAN
Connectivity technology	Wireless
Chipset	-
Internal	No
Certification	FCC B, IC
Product color	Black
LED indicators	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Frequency range	2.4 - 5 GHz
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	WPA, WPA2
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	867 Mbit/s
Output voltage	5 V
Power consumption	500 mA
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	138 mm
Package height	40 mm
Package weight	20 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	2025 mm
Pallet gross weight (air)	447400 g
Quantity per pallet (air)	1920 pc(s)
Harmonized System (HS) code	85176990
Shipping (inner) case width	292 mm
Shipping (inner) case height	300 mm
Shipping (inner) case length	425 mm
Shipping (inner) case weight	8800 g
Shipping (inner) case net weight	8000 g
Number of cartons per pallet (air)	48 pc(s)
Quantity per shipping (inner) case	40 pc(s)

Weight and Dimensions

Depth	97.3 mm
Width	29.1 mm
Height	13.5 mm
Weight	20.5 g
