D-Link DCH-M225 User Manual

25D-Link DCH-M225 User Manual
Section 3 - Conguration
Extended Wi-Fi Settings
This is the name of the DCH-M225’s extended network. The
DCH-M225 will rebroadcast the uplink router’s Internet
connection under this SSID. You can also choose to make
the SSID and password for the extended network the same
as the SSID and password for the uplink network. This means
the DCH-M225 will extend the network that your router is
currently broadcasting.
Select the type of wireless security you wish to use for
the extended network. Select None, WEP, or WPA/WPA2
Personal (recommended).
Enter the password or network key that you wish to use
for the extended network. You can also choose to make
the password for the extended network the same as the
password for the uplink network.
Click Save to save the settings and return to the Home page.
Wi-Fi Name
(SSID):
Security:
Password:
Save:
This page allows you congure the settings for the DCH-M225’s extended wireless network. To access this page from the Home
page, click on the Settings drop-down menu at the top of the page, and select Extended Wi-Fi.

D-Link DCH-M225 Specifications

General

Type	AV transmitter
Antenna type	Internal
Certification	FCC\\r IC\\r Wi-Fi Certified\\r CE
Product color	White
LED indicators	Yes
Maximum resolution	- pixels
Compatible products	DLNA, AirPlay
Security algorithms	128-bit WEP, 64-bit WEP, WPA, WPA2, WPS
Audio input	1
Frequency	2400 MHz
Connector(s)	3.5mm Audio
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	110-125 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Weight	81.6 g
Dimensions (WxDxH)	54.1 x 41.9 x 54.61 mm
