D-Link DIR-878 User Manual

DIR-878 AC1900 MU-MIMO Wi-Fi Gigabit Router
User Manual
Configuring via Web-based Interface
)
On the System / Log page, you can set the system log options and configure sending the system
log to a remote host.
Figure 132. The System / Log page. The Settings tab.
To enable logging of the system events, go to the Settings tab and move the Enable switch to the
right. Then specify the needed parameters.
Parameter Description
Type
Select a type of logging from the drop-down list.
• Local: the system log is stored in the router's memory. When
this value is selected, the Server and Port fields are not
displayed.
• Remote: the system log is sent to the remote host specified in
the Server field.
• Remote and local: the system log is stored in the router's
memory and sent to the remote host specified in the Server
field.
Level Select a type of messages and alerts/notifications to be logged.
Server
The IP or URL address of the host from the local or global network,
to which the system log will be sent.
Port
A port of the host specified in the Server field. By default, the value
514 is specified.
After specifying the needed parameters, click the APPLY button.
To disable logging of the system events, move the Enable switch to the left and click the APPLY
button.
To view the system log, go to the Log tab.
Page 171 of 191

D-Link DIR-878 Specifications

General

Color	black
Wi-Fi Speed	1900 megabits per second
Wi-Fi Mesh System	no
Frequency Band	2.4 ghz, 5.0 ghz
Ethernet Standard	10/100/1000
Ethernet Switch	yes
Wireless Networking Standard	wi-fi 5
Wireless Standard	ac, n
2.4 Ghz Streams	1
5.0 Ghz Streams	1
Gigabit Ethernet Speed	yes
Antennas	4
Firewall	nat, spi
Data Encryption	yes
Encryption Type	wpa, wpa2
Ports	rj-45
WAN Ports	1

Weight and Dimensions

Height	1.8 inches
Width	10.2 inches
Net Weight	1.2 pounds
