D-Link DIR-878 User Manual

DIR-878 AC1900 MU-MIMO Wi-Fi Gigabit Router
User Manual
Configuring via Web-based Interface
'
In order to connect your device to a wired ISP, on the Device mode page, from the Connection
method list, select the Wired connection value. Then from the Work mode list select the
Router value. In this mode you can configure a WAN connection, set your own settings for the
wireless network in the 2.4GHz and 5GHz bands, configure LAN ports to connect an STB or VoIP
phone, and set your own password for access to the web-based interface of the device.
Figure 23. Selecting an operation mode. The Router mode.
In order to connect your device to a wireless ISP (WISP), on the Device mode page, from the
Connection method list, select the Wi-Fi value. Then from the Work mode list select the
WISP Repeater value. In this mode you can connect your device to another access point,
configure a WAN connection, set your own settings for the wireless network in the 2.4GHz and
5GHz bands, configure LAN ports to connect an STB or VoIP phone, and set your own password
for access to the web-based interface of the device.
Figure 24. Selecting an operation mode. The WISP Repeater mode.
Page 36 of 191

D-Link DIR-878 Specifications

General

Color	black
Wi-Fi Speed	1900 megabits per second
Wi-Fi Mesh System	no
Frequency Band	2.4 ghz, 5.0 ghz
Ethernet Standard	10/100/1000
Ethernet Switch	yes
Wireless Networking Standard	wi-fi 5
Wireless Standard	ac, n
2.4 Ghz Streams	1
5.0 Ghz Streams	1
Gigabit Ethernet Speed	yes
Antennas	4
Firewall	nat, spi
Data Encryption	yes
Encryption Type	wpa, wpa2
Ports	rj-45
WAN Ports	1

Weight and Dimensions

Height	1.8 inches
Width	10.2 inches
Net Weight	1.2 pounds
