DIR-878 AC1900 MU-MIMO Wi-Fi Gigabit Router
User Manual
Configuring via Web-based Interface
)%*+
This configuration step is available for the Access point, Repeater, and Client modes.
1. Select the Automatic obtainment of IPv4 address to let DIR-878 automatically obtain
the LAN IPv4 address.
!
If the router obtains the LAN IPv4 address automatically, then after finishing the Wizard
you can access the web-based interface using the domain name (by default,
dlinkrouter.local ) with a dot at the end.
If you want to manually assign the LAN IPv4 address for DIR-878, do not select the Automatic
obtainment of IPv4 address checkbox and fill in the IP address and Netmask fields and, if
needed, the Gateway IP address field. Make sure that the assigned address does not coincide
with the LAN IPv4 address of the router to which your device connects.
Figure 28. The page for changing the LAN IPv4 address.
2. Click the NEXT button to continue or click the BACK button to return to the previous page.
Page 39 of 191
