-22-
Description of Each Block
Output
Minimum Maximum
Output Current
Board
Voltage
output output Condition
voltage voltage MIN NOR MAX
+29Vdc +27.0Vdc +32.0Vdc 0.1A 0.5A 1A
+24Vdc +22.3Vdc +25.4Vdc 0.1A 6.0A 7.0A PWR-CTL
DEP +12Vdc +11.00Vdc +12.00Vdc 0.1A 1.5A 2.0A ON
+5Vdc +4.75Vdc +5.25Vdc 0.1A 1.5A 2.5A
ST +5Vdc +4.75Vdc +5.25Vdc 0.1A 0.5A 0.6A
PWR-CTL
OFF
• Ripple and Noise
AC ripple,
Output Voltage switching ripple
Output and noise
Condition
Name Minimum Maximum
output output Continuous
voltage voltage
+29V +27.0Vdc +32.0Vdc
PWR-CTL
+24V +22.3Vdc +25.4Vdc
500mVp-p
ON
+12V +11.00Vdc +12.00Vdc
+5V +4.75Vdc +5.25Vdc MAX LOAD
ST +5V +4.75Vdc +5.25Vdc 500mVp-p PWR-CTL
Other Lines Don’t Care OFF
4-3. POWER PCB
4-3-1. POWER SPEC
• Rating : 110V~240V
• Regulating Method :
• Input Frequency : 50/60Hz
• Inrush Current : Below 80A at AC230V
• Output Voltage and Current are shown below.
