11. Part List
ZZ100 48B5454D06 TRANSMITTER REMOCON R-54D06 (AAA)
ZZ110 PTACPWG151 ACCESSORY AS DLP-26C3AMBS
60 4850Q01210 BATTERY LR03 AAA ALKALINE
M212 4852176101 COVER BOTTOM ABS BK
M681 4856819300 CLAMP WIRE NYLON 66
M821 4858213803 BAG INSTRUCTION L.D.P.E TO.05X250X400(+20)
M861 48586210E1 MANUAL INSTRUCTION ENGLISH
P801A 48599DM000 CORD POWER AS EU LP-33+LS-60L=2.0M(LF)
ZZ120 PTBCSHG149 COVER BACK AS DLT-26C3AMBS
M211 4852176901 COVER BACK HIPS BK
M211A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M211B 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M322 4853829200 FRAME WALL KIT SECC T=2.0
M322A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
ZZ130 PTPKCPG146 PACKING AS DLX-26C3AMBS
M681 4856812400 BAND PP AUTO T1.1XW17MMXL770M
M801 4858071500 BOX CARTON DW-3
M811 485819CS00 PAD EPS
M822 4858215701 BAG P.E PE FOAM t0.5x1050x950
ZZ140 PTCACAG151 CABINET AS DLP-26C3AMBS
M191 4851957400 SHIELD CASE AS 7255700+5944600
M201C 4856815900 CLAMP WIRE EGI T0.4+TUBE+PIE 3.2
M201D 7173301052 SCREW TAPPTITE TT2 BIN 3X10 MFZN BK 3CR
M321 4853296800 BRKT STAND SECC T1.6
M321A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M322 4853296900 BRKT STAND BOX SECC T1.0
M322A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M381C 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M381G 7003401052 SCREW MACHINE BIN 4X10 MFZN BK 3CR
M383 4853828900 FRAME BAR SECC T=1.2 (A-1 : AUO,SSE PANEL)
M383A 7003401052 SCREW MACHINE BIN 4X10 MFZN BK 3CR
M383B 7172401652 SCREW TAPPTITE TT2 TRS 4X16 MFZN BK 3CR
M541 4855421200 SPEC PLATE P.E 149X59
M721A 7173301052 SCREW TAPPTITE TT2 BIN 3X10 MFZN BK 3CR
M723 4857255900 SHIELD JACK AL 1100 T=1.0 (A-1 : SL-223P)
M723A 7173301052 SCREW TAPPTITE TT2 BIN 3X10 MFZN BK 3CR
M723B 7173301052 SCREW TAPPTITE TT2 BIN 3X10 MFZN BK 3CR
MK625 4850K01700 CORE FERRITE BNF-1130
P520A 4859004160 CABLE LVDS 1001-31FC-N+FH10002-30+3212APSB=300
P803B 4850714N06 CONNECTOR 20022HS-14S+SMH200-14P+ULW=300
V901 485LD13265 LCD PANEL T260XW02 V5
ZZ200 PTFMSJG146 MASK FRONT AS DLX-26C3AMBS
M201 4852093601 MASK FRONT HIPS BK
M561 4855625500 MARK BRAND SILVER DIA-CUTTING
(DOUBLE FACED TAPE), L=80, P=30
M591 4855945100 DECO PLATE PC T2.0
ZZ210 PTSPPWG151 SPEAKER AS DLP-26C3AMBS
P625 4850702N24 CONNECTOR SMH250-02+YRT205+YRT110+USW=1000
P626 4850703N42 CONNECTOR SMH250-03+YRT205+YRT110+USW=1000
SP01 4858318510 SPEAKER SP-45165F01C
SP01A 4856017800 SCREW SPKR FIX SWRM+SECC 3CR
SP02 4858318510 SPEAKER SP-45165F01C
SP02A 4856017800 SCREW SPKR FIX SWRM+SECC 3CR
ZZ250 PTSNSWG118 STAND AS DLD-32C1SMR
M213 4852177301 COVER STAND BASE HIPS BK
M383 4853831001 FRAME STAND ABS BK
M383A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M521 4855219100 PLATE BASE STAND SECC T2.0
M521A 7115401051 SCREW TAPPING FLT 4X10 MFZN 3CR
M521C 4852937500 RUBBER BOTTOM CR60 BK PHI 18.0 X T 3.0
ZZ300 PTDGMSG117 PCB DIGITAL MANUAL AS DLP-26C2AMSB
100 2193110012 SOLDER WIRE SAC3000 3.0MM (LFA3C0-W3.0)
200 2193110024 SOLDER WIRE SAC3005 1.6MM (LFA3-107-W1.6)
300 2291050623 FLUX SOLDER LF SV-PBF-304P(0.823)
400 2291050312 FLUX SOLVENT S-3000
C216 CEXE1C471E C ELECTRO 16V RM 470MF (8X11.5) TP
C255 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C267 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
LOC PART CODE PART NAME DESCRIPTION REMARK
C638 CEXF1H471V C ELECTRO 50V RSS 470MF (13X20) TP
C681 CEXF1E331V C ELECTRO 25V RSS 330MF (10X12.5)TP
C682 CEXF1E331V C ELECTRO 25V RSS 330MF (10X12.5)TP
C683 CEXF1E331V C ELECTRO 25V RSS 330MF (10X12.5)TP
C684 CEXF1E331V C ELECTRO 25V RSS 330MF (10X12.5)TP
HS505 4857032501 HEAT SINK AL EX BK L=26
IC703 124LC32A-P IC EEPROM 24LC32A-I/P 32K 8 PIN DIP STICK
JP201 4959200160 CONN D-SUB SHF-015-B111-22/BR2-J0.6
JP205 4959102340 JACK PHONE YKB21-5157
JP207 4859112950 JACK SCART DSSM-0378 STR
JP208 4859112950 JACK SCART DSSM-0378 STR
JP209 4859105340 JACK S-VHS DSW-10 (STRAIGHT)
JP210 4859117450 JACK PIN DPSS-0173S
JP211 4859117550 JACK PIN DPSE-0375S
JP603 97P6316100 JACK HEAD PHONE DHSE-9959
JP604 4859201170 CONN OPTICAL SENSOR OJ107A-T050-SHS
JP705 4859201460 CONN D-SUB 9P SHRA0209011
L606 58C0000166 COIL CHOKE CH-220N
L610 58C0000166 COIL CHOKE CH-220N
M321 4853294100 BRKT POWER SW SECC 1T
M321A 7172401452 SCREW TAPPTITE TT2 TRS 4X14 MFZN BK 3CR
M381 4853828700 FRAME MAIN PCB SECC T=1.0
M381D 7178301052 SCREW TAPPTITE TT2 WAS 3X10 MFZN BK 3CR
M381E 7008300851 SCREW MACHINE WAS 3X8 MFZN 3CR
M381F 4956800200 CLAMP WIRE WS-A-2-19
M381H 4853748800 RETA PCB NYLON 66
P540 4859295420 CONN WAFER 4602-04MV2-60-1 PLUG 4P ST
P625A 4959240520 CONN WAFER SMW250-02
P626A 4859284420 CONN WAFER SMW250-03
P701 4859295420 CONN WAFER 4602-04MV2-60-1 PLUG 4P ST
P702 4859295420 CONN WAFER 4602-04MV2-60-1 PLUG 4P ST
P705 485923162S CONN WAFER YW025-03 (STICK)
P802A 4850708S28 CONNECTOR YH025-08+YBNH250-08+ULW=550
P803A 4850704S62 CONNECTOR YH025-04+YBNH250-04+ULW=150
P804A 4859235120 CONN WAFER YW025-08
TU101 4859728530 TUNER VARACTOR FQ1216ME/IH-5 (HORI/DIN)
X401 5XJ28R32GE CRYSTAL QUARTZ HC-49/S 28.322MHZ 30PPM 16PF
X601 5XE18R432E CRYSTAL QUARTZ HC-49/U 18.43200MHZ 30PPM
X701 5XE10R000E CRYSTAL QUARTZ HC-49/U 10.00000MHZ 30PPM
ZZ200 PTDGJ2G117 PCB DIGITAL CHIP B AS DLP-26C2AMSB
CC147 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CC148 HCQK101JBA C CHIP CERA 50V CH 100PF J 1608
CC213 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC234 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC243 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CC249 HCQK100JBA C CHIP CERA 50V CH 10PF J 1608
CC251 HCQK100JBA C CHIP CERA 50V CH 10PF J 1608
CC270 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CC277 HCBK102KBA C CHIP CERA 50V X7R 1000PF K 1608
CC283 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
CC285 HCQK331JBA C CHIP CERA 50V CH 330PF J 1608
CC288 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC406 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC407 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC409 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC412 HCBK472KBA C CHIP CERA 50V X7R 4700PF K 1608
CC413 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC414 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC415 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CC416 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CC417 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CC418 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CC419 HCBK103KBA C CHIP CERA 50V X7R 0.01MF K 1608
CC471 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC472 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC473 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC474 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
CC475 HCBK104KBA C CHIP CERA 50V X7R 0.1MF K 1608
LOC PART CODE PART NAME DESCRIPTION REMARK
DLP-26C3
