SERVICE MODE
-26-
• Name : _____
• System : PAL
• Sound : BG
• Fine Tuning : 0
- Edit
5-2. Entering SERVICE MODE
Using the Service Remote controller, you can enter service mode directly.
5-2-1. Adjustment REMOCON and EEPROM initial DATA
A. The adjustment Specification use the SERVICE REMOCON R-34SVC
(S/N: 48B3034SVC)
B. Adjustment DATA
Key Name Details
Function
Remark
Default Adjustment
S1 Heat-Run
S2 - Gumi Channel Map Write
S3 Volume Test Volume : 0 -> 32 -> 63 -> L -> R
1. Connect P701(Jumper) of Main PCB.
2. Press the "S4" key of service remocon.
S4 EDID write Operating Method And then, TV set display "EDID WRITE OK"
upper left of screen.
3. After EDID WRITE, remove P701(Jumper)
S5 PANEL TEST PATTEN : BLACK -> WHITE -> RED -> GREEN -> BLUE
PATTEN : BRIGHT MIN -> CEN -> MAX ->
S6
PICTURE TEST
CONTRAST MIN -> CEN -> MAX ->
COLOR MIN -> CEN -> MAX
S7 - DEMPOL Channel Map Write
1. Press the "S8"key of service remocon.
EEPROM Erase 2. Press the "OK"key of user remocon.
operating method And then, TV set display "EEPROM CLEARED"
upper left of screen.
White
3. When you turn off/on AC, EEPROM data will be cleared.
balance Default Adjustment
S8 /EEPROM 26"(32") - FIX
Erase CUT OFF R 379(400) - FIX
CUT OFF G 447(448) - FIX
CUT OFF B 431(403) - FIX
DRIVE R 373(340) - FIX
DRIVE G 328(310) - FIX
DRIVE B 322(330) - FIX
AUTO Y CLAMP DO NOT USE
AUTO Y GAIN DO NOT USE
