Daewoo DLT-26C2 User Manual

16
PC INPUT PC AUDIO
S-VIDEO
AV3 L - AUDIO - R
OPTICAL
COMPONENT
Pr
RL
Pb Y
PC INPUT PC AUDIO
S-VIDEO
AV3 L - AUDIO - R
OPTICAL
COMPONENT
Pr
RL
Pb Y
PC
Connection
When connecting with PC(D-Sub) cable.
1. First adjust resolution of the PC. (Refer to table in page 17.)
2. Connect between PC and TV set using the D-sub and Audio cable as shown in the picture below.
3. Turn on the PC and TV set.
4. Select PC mode by pressing the “MULTIMEDIA” button on the remote control or ”
” button of the TV set.
Back of the tv set
PC
When connecting with a HDMI cable.
1. First adjust resolution of the PC. (Refer to table in page 17.)
2. Connect between PC and TV set using the HDMI and Audio cable as shown in the picture below.
3. Turn on the PC and TV set.
4. select HDMI mode by pressing the “MULTIMEDIA” button on the remote control or ”
” button of the TV set.
PC
Back of the tv set
Note : If the graphic card of the PC only supports a DVI signal, you must connect the Audio cable as shown in the
picture upper.
