- 11 -
System Connections
Connecting to External AV Input Device (AV Output)
Use the AV cables to connect the external AV input device to the AV output jacks on the side panel
of the unit.
Note: The unit can output TV, COMPOSITE, S-VIDEO and SCART-COMPOSITE signals.
After connection, turn on the power of the unit and external AV input device and then press the
SOURCE button to select the corresponding mode.
Connecting to Earphones
Connect earphones (headphones) to the earphone jack on the rear panel of the unit for listening to
the audio output in seclusion.
◆ The internal speakers output will turn off automatically after the earphones have been
connected.
Note:
Excessively loud volume could damage your hearing. So turn down the volume before connecting
earphone, and then raise the volume to a comfortable level.
