18
Figure 4-20 Add channel
2) Configure the parameters.
Table 4-5 Description of adding channel
Parameter Description
Protocol
Select a protocol depending on the device or platform that is connected.
●
When the box is connected to IVSS (intelligent video surveillance
server) or IP camera, select
Acquisition
.
●
When the box is connected to SmartPSS, select
PSS
.
●
When the box is connected to DSS, select
DSS
.
IP Address
Enter the IP address of the IP camera, IVSS, DSS, or PSS, depending on the
Protocol
that you select.
You can add up to 8
Acquisition
channels. 1
DSS
channel, and 1
PSS
channel. The channels must not conflict with each other.
Port
Port for logging in to the IP camera, IVSS, DSS, or PSS. It is 37777 by default
for the IP camera and IVSS, and 8101 for DSS and PSS.
Channel
You need to enter channel No. when IP camera or IVSS is connected.
●
Enter 1 when IP camera is connected.
●
Enter the channel No. assigned by IVSS when IVSS is connected.
Username Username and password for logging in to the IP camera or IVSS.
You need to enter the username and password when
Acquisition
is
selected in
Protocol
.
Password
Stream Type
●
Main stream: Provides large bit stream and images with high
resolution, but requires large amount of bandwidth.
●
Sub stream: Sub stream 1 or sub stream 2 are available. Provides small
bit stream and a smooth image, and requires less bandwidth.
To Next Page
