Table 2-20 Ports
Port Name
Connection
Function
USB port
USB port. Connect to mouse, USB storage
device, USB burner and more.
Network port
10/100 Mbps self-adaptive Ethernet port.
Connect to the network cable.
HDMI
High Definition
Media Interface
High definition audio and video signal
output port. It transmits uncompressed high
definition video and multiple-channel data
to the HDMI port of the display device.
HDMI version is 1.4.
VGA
VGA video output
port
VGA video output port. Output analog video
signal. It can connect to the monitor to view
analog video.
GND
Ground end.
/
Power input port
Power socket.
●
For N41C1P/N41C2P: 12 VDC/2 A power.
●
For NVR41-P-4KS2: 48 VDC/72 W power.
●
For NVR41-8P-4KS2: 48 VDC/96 W
power.
MIC IN
Audio input port
Bidirectional talk input port. It is to receive
the analog audio signal output from the
devices such as microphone, pickup.
MIC OUT
Audio output port
Audio output port. It is to output the analog
audio signal to the devices such as the sound
box.
●
Bidirectional talk output.
●
Audio output on 1-window video
monitor.
●
Audio output on 1-window video
playback.
PoE PORTS
PoE port
Built-in switch. Support PoE function.
For PoE series product, you can use this port
to provide power to the network camera.
2.2.2
N42C1P/N42C2P/N42C3P/N52B5P/N54A4P/N54B3P/N54B5N
The N42C1P series rear panel is shown as below.
