ESIE16-02B | Part 3. Repair 3.3. Unit specific repair procedures
Page 78 4/04/17 | Version 1.1
RA R32 Split & multi split M-Series
Installation
1. Check damper status, replace when worn.
2. First install the 3 (new) dampers (without the bushings) on the new compressor.
3. Install the 3 bushings in the dampers.
4. When installing the new compressor, remove the caps from the compression pipe and the suction pipe as late as possible.
5. When soldering the compressor pipes, cover the compressor pipes with a wet cloth to prevent overheating the compressor
(and the oil in the compression pipe).
6. Proceed in reverse order.
CAUTION
The oil in the compressor is hygroscopic. Remove the caps from the compressor piping as late as possible.
INFORMATION
Before installing a new compressor, determine the cause of the compressor failure and take all required corrective
actions.
INFORMATION
If the dampers are worn, replace the dampers. The bushings inside the dampers are recuperated for use with the new
dampers.
INFORMATION
Install the putty on the compressor.
Install the compressor sound insulation in the same location.

Daikin 2MXM50M Specifications

General

Type	Air conditioner outdoor unit
Multi-split	-
Product color	White
Gas hose diameter	9.5 mm
Drain hose diameter	16 mm
Liquid hose diameter	6.35 mm
Outdoor unit depth	285 mm
Outdoor unit width	765 mm
Outdoor unit height	550 mm
Outdoor unit weight	41000 g
Outdoor unit noise level	486.35 dB
Outdoor unit package depth	357 mm
Outdoor unit package width	900 mm
Outdoor unit package height	614 mm
Outdoor unit package weight	43000 g
Outdoor unit sound power level	62 dB
Current	16 A
AC input voltage	220 - 240 V
AC input frequency	50 Hz
