EDUS121503A Specifications
Multi-Split Type Air Conditioners 2/3/4MXS-N Series 19
1
60 Hz, 208 - 230 V
Notes:
1.
+
1 See page 25 “Combination Capacity”.
2.
+
2 Max.: for the combination of wall mounted type indoor units
Min.: for the combination of duct connected type indoor units
3. The data are based on the conditions shown in the table below.
Model
3MXS24NMVJU
Cooling Heating
Capacity
+
1kW —
Power Consumption
+
1W —
Running Current
+
1A —
COP
+
2 W/W — 3.2
~
4.6
EER
+
2 Btu/h·W 9.7
~
12.7 —
SEER / HSPF 14.0
~
17.9 8.2
~
12.5
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 2YC63AAXD
Motor Output W 1,920
Refrigerant Oil
Model FVC50K
Charge oz (L) 29.8 (0.85)
Refrigerant
Type R-410A
Charge Lbs (kg) 6.17 (2.8)
Airflow Rate
H
cfm
2,094 2,094
M 2,094 1,981
L 1,981 1,119
H
m³/min
59.3 59.3
M 59.3 56.1
L 56.1 31.7
Fan
Type Propeller
Motor Output W 51
Running Current A H: 0.28 / M: 0.28 / L: 0.26 H: 0.28 / M: 0.26 / L: 0.05
Power Consumption W H: 63 / M: 63 / L: 59 H: 63 / M: 59 / L: 12
Starting Current A 15.5
Dimension (H × W × D) in. (mm) 28-15/16 × 34-1/4 × 12-5/8 (735 × 870 × 320)
Packaged Dimension (H × W × D) in. (mm) 31-7/8 × 41-9/16 × 17-1/2 (810 × 1,056 × 444)
Weight (Mass) Lbs (kg) 137 (62)
Gross Weight (Gross Mass) Lbs (kg) 154 (70)
Sound Pressure Level dB(A) 52 54
Piping
Connections
Liquid in. (mm) φ 1/4 × 3 (φ 6.4 × 3)
Gas in. (mm) φ 3/8 × 1, φ 1/2 × 2 (φ 9.5 × 1, φ 12.7 × 2)
Drain in. (mm) φ 11/16 (φ 17.5)
Heat Insulation Both Liquid and Gas Pipes
No. of Wiring Connections 3 for Power Supply, 4 for Interunit Wiring
Max. Interunit Piping Length ft (m)
230 (70) (for Total of Each Room)
82 (25) (for One Room)
Amount of Additional Charge of
Refrigerant
oz/ft
(g/m)
0.21 (20) (131-5/8 ft (40 m) or more)
Max. Installation Height Difference ft (m)
49-1/4 (15) (between Indoor Unit and Outdoor Unit)
24-5/8 (7.5) (between Indoor Units)
Drawing No. 3D093259
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling
Indoor ; 80°FDB (26.7°CDB) / 67°FWB (19.4°CWB)
Outdoor ; 95°FDB (35°CDB) / 75°FWB (24°CWB)
Heating
Indoor ; 70°FDB (21°CDB) / 60°FWB (15.6°CWB)
Outdoor ; 47°FDB (8.3°CDB) / 43°FWB (6°CWB)
Piping Length 25 ft (7.5 m)
To Next Page
