Daikin 2MXS-N Series User Manual

Specifications EDUS121503A
20 Multi-Split Type Air Conditioners 2/3/4MXS-N Series
60 Hz, 208 - 230 V
Notes:
1.
+
1 See page 37 “Combination Capacity”.
2.
+
2 Max.: for the combination of wall mounted type indoor units
Min.: for the combination of duct connected type indoor units
3. The data are based on the conditions shown in the table below.
Model
4MXS36NMVJU
Cooling Heating
Capacity
+
1kW —
Power Consumption
+
1W —
Running Current
+
1A —
COP
+
2 W/W — 3.5
~
4.5
EER
+
2 Btu/h·W 7.9
~
9.2 —
SEER / HSPF 14.0
~
17.7 8.2
~
12.2
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 2YC63AAXD
Motor Output W 1,920
Refrigerant Oil
Model FVC50K
Charge oz (L) 29.8 (0.85)
Refrigerant
Type R-410A
Charge Lbs (kg) 6.17 (2.8)
Airflow Rate
H
cfm
2,613 2,351
M 2,440 2,210
L 1,727 1,119
H
m³/min
74.0 66.6
M 69.1 62.6
L 59.3 31.7
Fan
Type Propeller
Motor Output W 75
Running Current A H: 0.52 / M: 0.40 / L: 0.27 H: 0.38 / M: 0.32 / L: 0.06
Power Consumption W H: 116 / M: 90 / L: 61 H: 85 / M: 72 / L: 14
Starting Current A 17.5
Dimension (H × W × D) in. (mm) 28-15/16 × 34-1/4 × 12-5/8 (735 × 870 × 320)
Packaged Dimension (H × W × D) in. (mm) 31-7/8 × 41-9/16 × 17-1/2 (810 × 1,056 × 444)
Weight (Mass) Lbs (kg) 139 (63)
Gross Weight (Gross Mass) Lbs (kg) 157 (71)
Sound Pressure Level dB(A) 54 56
Piping
Connections
Liquid in. (mm) φ 1/4 × 4 (φ 6.4 × 4)
Gas in. (mm) φ 3/8 × 1, φ 1/2 × 2, φ 5/8 × 1 (φ 9.5 × 1, φ 12.7 × 2, φ 15.9 × 1)
Drain in. (mm) φ 11/16 (φ 17.5)
Heat Insulation
Both Liquid and Gas Pipes
No. of Wiring Connections 3 for Power Supply, 4 for Interunit Wiring
Max. Interunit Piping Length ft (m)
230 (70) (for Total of Each Room)
82 (25) (for One Room)
Amount of Additional Charge of
Refrigerant
oz/ft
(g/m)
0.21 (20) (131-5/8 ft (40 m) or more)
Max. Installation Height Difference ft (m)
49-1/4 (15) (between Indoor Unit and Outdoor Unit)
24-5/8 (7.5) (between Indoor Units)
Drawing No. 3D093260
Conversion Formulae
kcal/h = kW × 860
Btu/h = kW × 3412
cfm = m³/min × 35.3
Cooling
Indoor ; 80°FDB (26.7°CDB) / 67°FWB (19.4°CWB)
Outdoor ; 95°FDB (35°CDB) / 75°FWB (24°CWB)
Heating
Indoor ; 70°FDB (21°CDB) / 60°FWB (15.6°CWB)
Outdoor ; 47°FDB (8.3°CDB) / 43°FWB (6°CWB)
Piping Length 25 ft (7.5 m)
