EWAQ016~064BAW + EWYQ016~064BAW
Packaged air-cooled water chiller
4PW70082-1C – 2013.07
Installation and operation manual
34
5.9.2. Programming
Programming space
Programming space cooling is carried out as follows:
1 Press the button to enter the programming/consulting mode.
2 Select the operation mode you would like to program by means
of the and buttons.
The actual mode is blinking.
3 Press the button to confirm the selected mode.
The time is blinking.
4 Consult the action by means of the and buttons.
5 Hold down the button for 5 seconds to program the detailed
actions.
The first programmed action appears.
6 Use the button to select the action number you would like to
program or to modify.
7 Use the and buttons to set the correct action time.
8 Use the and buttons to set the leaving water
temperature.
9 Use the and buttons to set the room temperature.
10 Use the button to select to switch cooling and the
remote controller off.
11 Repeat steps 6 to 10 to program the other actions.
When all actions have been programmed, make sure that the
display shows the highest action number you would like to save.
12 Press the button for 5 seconds to store the programmed
actions.
If the button is pressed when action number 3 is displayed,
actions 1, 2 and 3 are stored but 4 is deleted.
You automatically return to step 5.
By pressing the button several times, you return to previous
steps in this procedure and finally return to normal operation.
13 You automatically return to step 5, start again to program the
following day.
5 sec
5 sec
INFORMATION
Returning to previous steps in the programming procedure
without saving modified settings is done by pressing the
button.
4PWEN70082-1C.book Page 34 Wednesday, September 25, 2013 7:31 AM
