Physical Data
Unit Capacity and Physical Data
Table 5: RCS 06G – 20F Physical Data
Model
RCS
06G Single 07G Single 10G Single 12F Tandem 15F Tandem 20F Tandem
Capacity and Weight
Capacity (tons) [kW] 6.5 [22.9] 7.5 [26.4] 10 [35.2] 12 [42.2] 15 [52.8] 20 [70.3]
Number of circuits 1
Operating weight
(lbs) [Kg]
245 [111.1] 307 [139.2] 557 [253.0] 650 [294.8] 746 [338.4] 952 [431.8]
Shipping weight
(lbs) [Kg]
252 [114.3] 313 [141.9] 597 [271.0] 690 [313.0] 786 [356.5] 992 [450.0]
Compressor
Quantity 1 2
Type Scroll
RPM 3500
Capacity Control,
Stages
1 2
Refrigerant charge
R410A oz. [g]
219 [6209] 400 [11340] 437 [12,389] 378 [10,716] 506 [14,345] 655 [18,569]
Condenser Fans
Quantity 1 2 3
CFM [L/s] 5700 [2690] 5700 [2690] 8000 [3775] 8100 [3882] 12,000 [5663] 12,000 [5663]
Diameter (in.) [mm 26 [660] 26 [660] 24 [610] 24 [610] 24 [610] 24 [610]
Drive Direct
“Motor horsepower
each [W]”
1/2 [373] 1/2 [373] 1/3 [249] 1/3 [249] 1/3 [249] 1/3 [249]
Type ECM PSC
RPM 975 1075
Condenser Coil
Quantity 1 2
Rows 1 2 3
Fins per inch 22 22 18 22 22 22
Sq. ft. [m2] 28.38 [2.64] 28.38 [2.64] 32.88 [3.05] 33.9 [3.05] 40.38 [3.75] 40.38 [3.75]
Fins/tubes Aluminum/Copper
Cabinet
Finish Powder Coat
Sheet metal Galvanized
Gauge (nominal) top 20
Sides 20
Base rails 14
Refrigerant Connection
Vapor sweat
(in.) [mm]
1-1/8 [29] 1-1/8 [29] 1-3/8 [35] 1-3/8 [35] 1-5/8 [41.3] 1-5/8 [41.3]
Liquid sweat
(in.) [mm]
1/2 [13] 1/2 [13] 5/8 [16] 5/8 [16] 5/8 [16] 7/8 [22]
IM 962-4 • AIR-COOLED SPLIT SYSTEM CONDENSERS 8 www.DaikinApplied.com
