SiUS071735EB Field Settings
Trial Operation and Field Settings 126
4.2 Overview of the Field Settings
: Factory setting
Note: The SECOND CODE NO. is factory set to "01".
Do not use any settings not listed in the table. For group control with a wireless remote controller,
initial settings for all the indoor units of the group are equal. (For group control, refer to the
installation manual attached to the indoor unit for group control.)
External Static Pressure Settings
09/12 class : Factory setting
15/18/24 class
Mode
No.
First
Code
No.
Description of setting
Second Code No.
01 02 03 04 05 06
10
(20)
0
Filter cleaning
sign interval
(used to change
filter cleaning
display interval
according to filter
contamination)
Longlife
filter
Light
Approx.
2,500
hrs.
Heavy
Approx.
1,250
hrs.
————
Standard
filter
Approx.
200 hrs.
Approx.
100 hrs.
————
3
Filter cleaning sign (used to
set filter cleaning display ON/
OFF)
DisplayNo display————
11
(21)
7 Air volume adjustment
OFF
Air volume
adjustment
completion
Air volume
adjustment
start
———
13
(23)
6 External static pressure Refer to the table below.
Mode No. First Code No. Second Code No. Contents
13(23) 6
03 30 Pa
04 40 Pa
05 50 Pa
06 60 Pa
07 70 Pa
08 80 Pa
09 90 Pa
10 100 Pa
11 110 Pa
12 120 Pa
13 130 Pa
14 140 Pa
15 150 Pa
Mode No. First Code No. Second Code No. Contents
13(23) 6
05 50 Pa
06 60 Pa
07 70 Pa
08 80 Pa
09 90 Pa
10 100 Pa
11 110 Pa
12 120 Pa
13 130 Pa
14 140 Pa
15 150 Pa
To Next Page
