Piping Diagrams EDUS091128
18 Split Type Air Conditioners FTXS-L / FDXS-L Series
6. Piping Diagrams
6.1 Indoor Unit
6.1.1 Single Split Duct-Free System
FTXS09/12LVJU FTXS15/18LVJU
FTXS24LVJU
INDOOR UNIT
1/4 CuT
HEAT EXCHANGER
CROSS FLOW FAN
THERMISTOR
ON HEAT EXCH.
FIELD PIPING
1/4 CuT
M
FAN MOTOR
FIELD PIPING
3/8 CuT
CuT3/8
REFRIGERANT FLOW
COOLING
HEATING
4D074606
INDOOR UNIT
5/16 CuT
DISTRIBUTOR
HEAT EXCHANGER
CROSS FLOW FAN
FIELD PIPING
1/4 CuT
M
FAN MOTOR
HEADER
FIELD PIPING
1/2 CuT
1/2 CuT
REFRIGERANT FLOW
COOLING
HEATING
THERMISTOR
ON HEAT EXCH.
4D074609
INDOOR UNIT
5/16 CuT
DISTRIBUTOR
HEAT EXCHANGER
CROSS FLOW FAN
M
FAN MOTOR
HEADER
1/2 CuT
REFRIGERANT FLOW
COOLING
HEATING
FIELD PIPING
1/4 CuT
FIELD PIPING
5/8 CuT
THERMISTOR
ON HEAT EXCH.
4D074608
