Daikin RXS09LVJU Engineering Data

Capacity Tables EDUS091128
22 Split Type Air Conditioners FTXS-L / FDXS-L Series
7. Capacity Tables
7.1 Heat Pump
7.1.1 Single Split Duct-Free System
FTXS09LVJU + RXS09LVJU
<60 Hz, 208 V>
Cooling
Temp: Celsius
TC, SHC, PI: kW
Temp: Fahrenheit
TC, SHC: kBtu/h
PI: kW
Heating
Temp: Celsius
TC, PI: kW
Temp: Fahrenheit
TC: kBtu/h
PI: kW
AFR 10.8
BF 0.16
INDOOR OUTDOOR TEMPERATURE (°CDB)
EWB EDB 20 25 30 32 35 40
°C °C TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14.0 20.0 2.70 2.25 0.45 2.58 2.19 0.50 2.46 2.14 0.54 2.41 2.12 0.56 2.34 2.08 0.58 2.21 2.03 0.59
16.0 22.0 2.83 2.21 0.46 2.70 2.16 0.50 2.58 2.11 0.54 2.53 2.09 0.56 2.46 2.06 0.59 2.33 2.00 0.59
18.0 25.0 2.95 2.36 0.46 2.83 2.31 0.50 2.70 2.26 0.55 2.65 2.24 0.56 2.58 2.21 0.59 2.46 2.16 0.59
19.4 26.7 3.01 2.52 0.46 2.89 2.47 0.50 2.76 2.42 0.55 2.71 2.40 0.56
2.64 2.37 0.59 2.52 2.33 0.60
22.0 30.0 3.19 2.44 0.46 3.07 2.40 0.51 2.95 2.35 0.55 2.90 2.34 0.57 2.82 2.31 0.59 2.70 2.27 0.60
24.0 32.0 3.31 2.39 0.47 3.19 2.35 0.51 3.07 2.31 0.55 3.02 2.29 0.57 2.94 2.27 0.60 2.82 2.23 0.60
INDOOR OUTDOOR TEMPERATURE (°FDB)
EWB EDB 68 77 86 90 95 104
°F °F TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
57.2 68.0 9.23 7.68 0.45 8.81 7.49 0.50 8.39 7.29 0.54 8.22 7.22 0.56 7.97 7.10 0.58 7.55 6.91 0.59
60.8 71.6 9.64 7.56 0.46 9.22 7.37 0.50 8.80 7.19 0.54 8.64 7.12 0.56 8.39 7.01 0.59 7.97 6.84 0.59
64.4 77.0 10.06 8.04 0.46 9.64 7.87 0.50 9.22 7.70 0.55 9.05 7.63 0.56 8.80 7.53 0.59 8.38 7.37 0.59
67.0 80.0 10.27 8.58 0.46 9.85 8.42 0.50 9.43 8.26 0.55 9.26 8.19 0.56 9.00 8.10 0.59 8.59 7.94 0.60
71.6 86.0 10.89 8.32 0.46 10.47 8.18 0.51 10.05 8.03 0.55 9.88 7.98 0.57 9.63 7.89 0.59 9.21 7.75 0.60
75.2 89.6 11.30 8.14 0.47 10.88 8.01 0.51 10.46 7.88 0.55 10.30 7.83 0.57 10.05 7.75 0.60 9.63 7.62 0.60
AFR 11.9
INDOOR OUTDOOR TEMPERATURE(°CWB)
EDB –15 –10 –5 0 6 10
°C TC PI TC PI TC PI TC PI TC PI TC PI
15.0 1.68 0.51 2.01 0.53 2.35 0.56 3.16 0.73 3.64 0.77 3.96 0.80
21.1 1.57 0.52 1.91 0.55 2.25 0.57 3.04 0.75 3.52 0.79 3.84 0.82
22.0 1.53 0.53 1.87 0.55 2.21 0.58 2.99 0.76 3.47 0.80 3.79 0.82
24.0 1.49 0.53 1.83 0.56 2.17 0.59 2.95 0.77 3.42 0.80 3.74 0.83
25.0 1.47 0.54 1.81 0.56 2.15 0.59 2.92 0.77 3.40 0.81 3.72 0.83
27.0 1.43 0.54 1.77 0.57 2.10 0.59 2.87 0.78 3.35 0.81 3.67 0.84
INDOOR OUTDOOR TEMPERATURE (°FWB)
EDB 5 14 23 32 43 50
°F TC PI TC PI TC PI TC PI TC PI TC PI
59.0 5.72 0.51 6.87 0.53 8.03 0.56 10.80 0.73 12.42 0.77 13.51 0.80
70.0 5.37 0.52 6.52 0.55 7.67 0.57 10.38 0.75
12.00 0.79 13.10 0.82
71.6 5.23 0.53 6.38 0.55 7.53 0.58 10.22 0.76 11.84 0.80 12.93 0.82
75.2 5.09 0.53 6.24 0.56 7.39 0.59 10.05 0.77 11.68 0.80 12.76 0.83
77.0 5.01 0.54 6.17 0.56 7.32 0.59 9.97 0.77 11.60 0.81 12.68 0.83
80.6 4.87 0.54 6.03 0.57 7.18 0.59 9.80 0.78 11.43 0.81 12.51 0.84
