Daikin RXS09LVJU Engineering Data

Electric Characteristics EDUS091128
52 Split Type Air Conditioners FTXS-L / FDXS-L Series
11.Electric Characteristics
Indoor Unit Outdoor Unit
Power Supply COMP OFM IFM
Hz - Volts Voltage Range MCA MOP RHz RLA W FLA W FLA
FTXS09LVJU RXS09LVJU
60 - 208
MAX. 60 Hz, 253 V
MIN. 60 Hz, 187 V
8.00 15 46
3.2
23 0.22 23 0.15
60 - 230 2.9
FTXS12LVJU RXS12LVJU
60 - 208
MAX. 60 Hz, 253 V
MIN. 60 Hz, 187 V
8.75 15 68
4.4
23 0.22 23 0.15
60 - 230 3.9
FTXS15LVJU RXS15LVJU
60 - 208
MAX. 60 Hz, 253 V
MIN. 60 Hz, 187 V
13.75 20 50
4.7
53 0.32 48 0.31
60 - 230 4.2
FTXS18LVJU RXS18LVJU
60 - 208
MAX. 60 Hz, 253 V
MIN. 60 Hz, 187 V
13.75 20 65
6.6
53 0.32 48 0.32
60 - 230 5.9
FTXS24LVJU RXS24LVJU
60 - 208
MAX. 60 Hz, 253 V
MIN. 60 Hz, 187 V
17.50 20 42.6
7.9
66 0.40 48 0.57
60 - 230 7.1
FDXS09LVJU RXS09LVJU
60 - 208
MAX. 60 Hz, 253 V
MIN. 60 Hz, 187 V
8.00 15 57
4.1
23 0.22 62 0.52
60 - 230 3.7
FDXS12LVJU RXS12LVJU
60 - 208
MAX. 60 Hz, 253 V
MIN. 60 Hz, 187 V
8.75 15 82
5.9
23 0.22 62 0.52
60 - 230 5.3
Symbols: Note:
MCA : Min. circuit amps (A) 1. RLA is based on the following conditions.
Indoor temp. 80°FDB / 67°FDB (26.7°CDB / 19.4°CDB)
Outdoor temp. 95°FDB (35°CDB)
2. Maximum allowable voltage variation between phases is 2%.
3. Select wire size based on the larger value of MCA.
4. Instead of a fuse, use a circuit breaker.
5. Be sure to install a Ground Fault Circuit Interrupter / Earth Leakage
Circuit Breaker that can handle higher harmonics because this unit
uses an inverter, and therefore must be capable of handling high
harmonics in order to prevent malfunction.
MOP : Max. overcurrent protection (A)
RHz : Rated operating frequency (Hz)
RLA : Rated load amps (A)
OFM : Outdoor fan motor
IFM : Indoor fan motor
W : Fan motor rated output (W)
FLA : Full load amps (A)

Daikin RXS09LVJU Specifications

General

Brand	Daikin
Model	RXS09LVJU
Category	Air Conditioner
Language	English
