Daikin VAM Series User Manual

EDMMT712101 Sound Level
VAM-HVE/HVLT Series 99
10.Sound Level
10.1 Overall Sound Level
10.2 Sound Pressure Level
Ventilation Mode
220 V / 50 Hz
Ventilation Mode
240 V / 50 Hz
Total Heat
Exchange mode
Bypass mode
Total Heat
Exchange mode
Bypass mode
Fan Speed U-H H L U-H H L Fan Speed U-H H L U-H H L
VAM150HVE 33.0 30.5 23.0 33.5 31.5 23.0 VAM150HVE 34.0 32.0 25.5 34.0 33.0 25.5
VAM250HVE 33.0 31.5 23.0 33.0 31.0 23.5 VAM250HVE 34.0 32.5 25.5 34.0 32.5 25.5
VAM350HVE 32.0 30.0 26.5 32.5 31.0 27.0 VAM350HVE 33.0 31.5 28.5 33.5 32.0 29.0
VAM500HVE 36.0 35.0 32.0 36.0 35.0 32.0 VAM500HVE 37.0 36.0 34.0 37.0 36.0 34.0
VAM650HVE 37.5 36.0 34.0 39.5 38.0 35.5 VAM650HVE 38.0 36.5 35.0 40.0 38.5 36.5
VAM800HVE 41.5 39.5 36.0 41.5 39.5 36.0 VAM800HVE 42.5 41.0 38.5 42.5 41.0 38.5
VAM1000HVE 42.0 40.0 38.0 42.0 40.0 38.0 VAM1000HVE 43.0 41.0 39.5 43.0 41.0 39.5
VAM1500HVE 43.0 41.0 38.0 43.0 41.0 38.0 VAM1500HVE 44.0 42.5 40.5 44.0 42.5 40.5
VAM2000HVE 43.5 41.5 39.0 43.5 41.5 39.0 VAM2000HVE 44.0 43.0 41.0 44.0 43.0 41.0
Ventilation Mode
220 V / 60 Hz
Total Heat
Exchange mode
Bypass mode
Fan Speed U-H H L U-H H L
VAM150HVE/HVLT 34.0 28.0 20.0 36.0 28.5 20.5
VAM250HVE/HVLT 33.5 28.0 21.0 34.5 29.0 21.5
VAM350HVE/HVLT 34.5 27.5 22.0 34.5 27.5 23.0
VAM500HVE/HVLT 38.5 35.0 31.0 38.5 35.0 31.0
VAM650HVE/HVLT 38.0 37.0 32.5 42.0 39.0 33.5
VAM800HVE/HVLT 41.0 37.0 33.0 41.0 37.0 33.0
VAM1000HVE/HVLT 42.5 38.0 34.5 42.5 38.0 34.5
VAM1500HVE/HVLT 44.0 39.0 35.0 44.0 39.0 35.0
VAM2000HVE/HVLT 44.5 40.0 36.5 44.5 40.0 36.5
VAM150HVE / VAM150HVLT
dB(A)
VAM250HVE / VAM250HVLT
dB(A)
Model Power Supply 63 125 250 500 1000 2000 4000 8000 Model Power Supply 63 125 250 500 1000 2000 4000 8000
VAM
150
HVE
50 Hz
220 V
U-H 41.247.934.625.322.519.314.815.0
VAM
250
HVE
50 Hz
220 V
U-H 42.3 47.9 34.5 25.5 22.7 19.3 14.7 15.2
H 38.9 45.5 32.1 23.1 20.2 17.1 13.2 13.8 H 39.4 45.8 32.8 23.8 20.8 17.7 13.9 14.5
L 35.7 33.5 24.9 16.7 14.2 11.3 10.8 12.5 L 36.0 33.2 24.5 16.8 14.2 11.5 11.3 13.1
230 V
U-H 41.748.435.125.823.019.815.315.5
230 V
U-H 42.8 48.4 35.0 26.0 23.2 19.8 15.2 15.7
H 39.9 46.5 33.1 24.1 21.2 18.1 14.2 14.8 H 40.4 46.8 33.8 24.8 21.8 18.7 14.9 15.5
L 37.7 35.5 26.9 18.7 16.2 13.3 12.8 14.5 L 38.0 35.2 26.5 18.8 16.2 13.5 13.3 15.1
240 V
U-H 42.248.935.626.323.520.315.816.0
240 V
U-H 43.3 48.9 35.5 26.5 23.7 20.3 15.7 16.2
H 40.4 47.0 33.6 24.6 21.7 18.6 14.7 15.3 H 40.9 47.3 34.3 25.3 22.3 19.2 15.4 16.0
L 38.2 36.0 27.4 19.2 16.7 13.8 13.3 15.0 L 38.5 35.7 27.0 19.3 16.7 14.0 13.8 15.6
VAM150
HVE/
HVLT
60 Hz 220 V
U-H 42.647.636.026.624.420.815.615.2
VAM250
HVE/
HVLT
60 Hz 220 V
U-H 41.1 47.6 34.8 25.6 23.2 20.3 15.6 15.4
H 36.9 43.1 29.4 20.6 17.6 14.5 10.3 11.0 H 38.5 42.3 29.9 21.0 18.1 14.6 11.8 12.9
L 33.8 28.8 20.9 13.1 11.1 9.5 10.2 12.1 L 36.8 29.7 21.6 14.3 11.9 10.4 11.3 13.1
VAM350HVE / VAM350HVLT
dB(A)
VAM500HVE / VAM500HVLT
dB(A)
Model Power Supply 63 125 250 500 1000 2000 4000 8000 Model Power Supply 63 125 250 500 1000 2000 4000 8000
VAM
350
HVE
50 Hz
220 V
U-H 40.745.632.425.822.218.714.113.9
VAM
500
HVE
50 Hz
220 V
U-H 48.6 49.1 37.8 29.9 27.7 23.3 16.2 14.9
H 39.9 43.1 30.8 24.1 20.3 16.7 13.5 14.0 H 47.6 47.6 36.5 29.3 27.7 22.2 15.7 14.3
L 37.9 38.0 26.7 21.1 18.8 14.5 13.6 15.1 L 46.0 42.5 33.9 29.2 24.1 19.6 15.3 15.5
230 V
U-H 41.246.132.926.322.719.214.614.4
230 V
U-H 49.1 49.6 38.3 30.4 28.2 23.8 16.7 15.4
H 40.9 44.1 31.8 25.1 21.3 17.7 14.5 15.0 H 48.1 48.1 37.0 29.8 28.2 22.7 16.2 14.8
L 39.4 39.5 28.2 22.6 20.3 16.0 15.1 16.6 L 47.5 44.0 35.4 30.7 25.6 21.1 16.8 17.0
240 V
U-H 41.746.633.426.823.219.715.114.9
240 V
U-H 49.6 50.1 38.8 30.9 28.7 24.3 17.2 15.9
H 41.4 44.6 32.3 25.6 21.8 18.2 15.0 15.5 H 48.6 48.6 37.5 30.3 28.7 23.2 16.7 15.3
L 39.9 40.0 28.7 23.1 20.8 16.5 15.6 17.1 L 48.0 44.5 35.9 31.2 26.1 21.6 17.3 17.5
VAM350
HVE/
HVLT
60 Hz 220 V
U-H 42.447.534.427.525.020.015.114.3
VAM500
HVE/
HVLT
60 Hz 220 V
U-H 51.4 51.0 41.5 33.6 29.0 25.5 18.9 16.1
H 39.0 40.5 27.8 21.7 18.7 14.8 13.6 15.3 H 47.7 48.7 36.1 28.5 27.6 21.7 15.1 14.1
L 35.4 31.5 21.3 16.4 12.9 11.2 12.2 14.0 L 44.9 42.5 32.3 26.7 23.2 18.5 14.2 14.8
Hz
Notch
Hz
Notch
Hz
Notch
Hz
Notch
