Details of Optional Accessories EDMMT712101
162 VAM-HVE/HVLT Series
15.5 KDDM24B100: Silencer
Applications and features
The silencer effectively reduces the noise of the Heat Reclaim Ventilator (VAM series).
Airflow rate does not drop up to 1000 m
3
/ h.
Caution
The silencer cannot be used on different model. Confirm the model before installation.
15.5.1 Dimensions
KDDM24B100
Part No. KDDM24B100
Applicable model
VAM500HVE, VAM650HVE
VAM500HVLT, VAM650HVLT
VAM800HVE, VAM1000HVE,
VAM1500HVE, VAM2000HVE
VAM800HVLT, VAM1000HVLT,
VAM1500HVLT, VAM2000HVLT
Nominal pipe diameter 200 mm 250 mm
Noise suppression effect
Approx. 6 dB
hole
hole
J: D3K03771B
Characteristics of filter
Pressure loss
Air volume
