Danfoss AK-PC 772A User Manual

80 Capacity controller RS8HF102 © Danfoss 2017-07 AK-PC 772A
Check of settings
1. Go to the overview
2. Select suction group
3. Move on through all the individual displays for the
suction group
Change displays with the +- button. Remember the settings at
the bottom of the pages – the ones that can only be seen via
the ”Scroll bar”.
4. Check the individual pages
5. Go back to the overview. Repeat for LT
Before the control starts, we check that all the settings are as they
should be.
The overview display will now show one line for each of the general
functions. Behind each icon there is a number of displays with the
different settings. It is all these settings that have to be checked.
The last page contains control data
