Danfoss EtherNet/IP Midi Drive FC 280 User Manual

Parameter Default value 4 set-up
Change during
operation
Conversion
index
Type
Parameter 8-58 Prodrive OFF3
Select
[3] Logic OR All set-ups TRUE – Uint8
Parameter 8-79 Protocol Firmware
version
– 1 set-up FALSE -2 Uint16
Parameter 8-80 Bus Message Count 0 1 set-up TRUE 0 Uint32
Parameter 8-81 Bus Error Count 0 1 set-up TRUE 0 Uint32
Parameter 8-82 Slave Messages
Rcvd
0 1 set-up TRUE 0 Uint32
Parameter 8-83 Slave Error Count 0 1 set-up TRUE 0 Uint32
Parameter 8-84 Slave Messages Sent 0 1 set-up TRUE 0 Uint32
Parameter 8-85 Slave Timeout Errors 0 1 set-up TRUE 0 Uint32
Parameter 8-88 Reset FC port
Diagnostics
[0] Do not reset 1 set-up TRUE – Uint8
Parameter 8-90 Bus Jog 1 Speed 100 RPM All set-ups TRUE 0 Uint16
Parameter 8-91 Bus Jog 2 Speed 200 RPM All set-ups TRUE 0 Uint16
Parameter 12-00 IP Address
Assignment
[10] DCP 1 set-up TRUE – Uint8
Parameter 12-01 IP Address 0 1 set-up TRUE – Oct. string 4
Parameter 12-02 Subnet Mask 0 1 set-up TRUE – Oct. string 4
Parameter 12-03 Default Gateway 0 1 set-up TRUE – Oct. string 4
Parameter 12-04 DHCP Server 0 1 set-up TRUE – Oct. string 4
Parameter 12-05 Lease Expires – All set-ups TRUE – Time di. w/date
Parameter 12-06 Name Servers 0 1 set-up TRUE – Oct. string 4
Parameter 12-07 Domain Name 0 1 set-up TRUE – Visible string 48
Parameter 12-08 Host Name 0 1 set-up TRUE – Visible string 48
Parameter 12-09 Physical Address 0 1 set-up TRUE – Visible string 17
Parameter 12-10 Link Status [0] No Link All set-ups TRUE – Uint8
Parameter 12-11 Link Duration – All set-ups TRUE – Time di. w/date
Parameter 12-12 Auto Negotiation [1] On 1 set-up TRUE – Uint8
Parameter 12-13 Link Speed [0] None 1 set-up TRUE – Uint8
Parameter 12-14 Link Duplex [1] Full Duplex 1 set-up TRUE – Uint8
Parameter 12-18 Supervisor MAC 0 2 set-ups TRUE 0 Oct. string 6
Parameter 12-19 Supervisor IP Addr. 0 2 set-ups TRUE 0 Oct. string 4
Parameter 12-20 Control Instance – 1 set-up TRUE – Uint8
Parameter 12-21 Process Data
Cong Write
[0] None All set-ups TRUE – Uint16
Parameter 12-22 Process Data
Cong Read
[0] None All set-ups TRUE – Uint16
Parameter 12-28 Store Data Values [0] O All set-ups TRUE – Uint8
Parameter 12-29 Store Always [0] O 1 set-up TRUE – Uint8
Parameter 12-30 Warning
Parameter
0 All set-ups TRUE 0 Uint16
Parameter 12-31 Net Reference [0] O All set-ups TRUE – Uint8
Parameter 12-32 Net Control [0] O All set-ups TRUE – Uint8
Parameter 12-33 CIP Revision – All set-ups TRUE – Uint16
Parameter 12-34 CIP Product Code – 1 set-up TRUE – Uint16
Parameter 12-35 EDS Parameter 0 All set-ups TRUE 0 Uint32
Parameter 12-37 COS Inhibit Timer 0 All set-ups TRUE 0 Uint16
Parameter 12-38 COS Filter 0 All set-ups TRUE 0 Uint16
Parameter 12-80 FTP Server [0] Disabled 1 set-up TRUE – Uint8
Parameter 12-81 HTTP Server [0] Disabled 1 set-up TRUE – Uint8
Parameter 12-82 SMTP Service [0] Disabled 1 set-up TRUE – Uint8
Parameters EtherNet/IP
32 Danfoss A/S © 06/2016 All rights reserved. MG07H102
