4.4 Field Installation of Options
4.4.1 Installation of Input Plate Options
This section is for the field installation of input option kits available for adjustable frequency drives in all D and E frames.
Do not attempt to remove RFI filters from input plates. Damage may occur to RFI filters if they are removed from the input plate.
NOTE!
Where RFI filters are available, there are two different types of RFI filters depending on the input plate combination and the RFI filters
interchangeable. Field installable kits in certain cases are the same for all voltages.
380–480 V
380–500 V
Fuses Disconnect Fuses RFI RFI Fuses RFI Disconnect
Fuses
D11 176F8443 176F8441 176F8445 176F8449 176F8447
E7 FC 102/ 202: 450 hp [315
kW]
FC 302: 335 hp [250 kW]
176F0253 176F0255 176F0257 176F0258 176F0260
FC 102/ 202: 500–600 hp
[355–450 kW]
FC 302: 450–550 hp
[315–400 kW]
176F0254 176F0256 176F0257 176F0259 176F0262
NOTE!
For further information, please see the Instruction Sheet,
175R5795
4.4.2 Installation of Line Power Shield for Adjustable Frequency Drives
The line power shield is for installation with D and E frames and satisfy BG-4 requirements.
Ordering numbers:
D frames: 176F0799
E frames: 176F1851
NOTE!
For further information, please see the Instruction Sheet,
175R5923
4 How to Install
VLT AQUA Low Harmonic Drive Instruction
Manual
4-30
MG.20.T1.22 - VLT
®
is a registered Danfoss trademark
