5.1.6 Q5 Changes Made
Q5 Changes Made can be used for fault finding.
Select
Changes made
to get information about:
• The last 10 changes. Use the up/down navigation keys to scroll between the last 10 changed parameters.
• The changes made since default setting.
Select
Loggings
to get information about the display line readouts. The information is shown in graphs.
Only display parameters selected in par. 0-20 and par. 0-24 can be viewed. It is possible to store up to 120 samples in the memory for later reference.
Please notice that the parameters listed in the below tables for Q5 only serve as examples since they will vary depending on the programming of the
particular adjustable frequency drive.
Q5-1 Last 10 Changes
20-94 PID Integral Time
20-93 PID Proportional Gain
Q5-2 Since Factory Setting
20-93 PID Proportional Gain
20-94 PID Integral Time
Q5-3 Input Assignments
Analog Input 53
Analog Input 54
5.1.7 Q6 Loggings
Q6 Loggings can be used for fault finding.
Please notice that the parameters listed in the table for Q6 below only serve as examples since they will vary depending on the programming of the
particular adjustable frequency drive.
Q6 Loggings
Reference
Analog Input 53
Motor Current
Frequency
Feedback
Energy Log
Trending Cont Bin
Trending Timed Bin
Trending Comparison
