Danfoss VLT AutomationDrive FC 303 User Manual

10.3.2 CE Compliance
Fuses or circuit breakers are mandatory to comply with IEC 60364. Danfoss recommend using a selection of the following.
The fuses below are suitable for use on a circuit capable of delivering 100,000 Arms (symmetrical), 240V, or 480V, or 500V,
or 600V depending on the Adjustable frequency drive voltage rating. With the proper fusing, the Adjustable frequency drive
short circuit current rating (SCCR) is 100,000 Arms.
Enclosure FC 300 Power Recommended
fuse size
Recommended
Max. fuse
Recommended circuit
breaker
Max. trip level
Size [kW] Moeller [A]
A1 0.25–1.5 gG-10 gG-25 PKZM0-16 16
A2 0.25–2.2 gG-10 (0.25–1.5)
gG-16 (2.2)
gG-25 PKZM0-25 25
A3 3.0–3.7 gG-16 (3)
gG-20 (3.7)
gG-32 PKZM0-25 25
B3 5.5 gG-25 gG-63 PKZM4-50 50
B4 7.5–1.5 gG-32 (7.5)
gG-50 (11)
gG-63 (15)
gG-125 NZMB1-A100 100
C3 18.5–22 gG-80 (18.5)
aR-125 (22)
gG-150 (18.5)
aR-160 (22)
NZMB2-A200 150
C4 30–37 aR-160 (30)
aR-200 (37)
aR-200 (30)
aR-250 (37)
NZMB2-A250 250
A4 0.25–2.2 gG-10 (0.25–1.5)
gG-16 (2.2)
gG-32 PKZM0-25 25
A5 0.25–3.7 gG-10 (0.25–1.5)
gG-16 (2.2–3)
gG-20 (3.7)
gG-32 PKZM0-25 25
B1 5.5–7.5 gG-25 (5.5)
gG-32 (7.5)
gG-80 PKZM4-63 63
B2 11 gG-50 gG-100 NZMB1-A100 100
C1 15–22 gG-63 (15)
gG-80 (18.5)
gG-100 (22)
gG-160 (15–18.5)
aR-160 (22)
NZMB2-A200 160
C2 30–37 aR-160 (30)
aR-200 (37)
aR-200 (30)
aR-250 (37)
NZMB2-A250 250
Table 10.1 200–240V, Frame Sizes A, B, and C
Specifications
VLT
®
AutomationDrive Instruction
Manual
MG.33.AI.22 - VLT
®
is a registered Danfoss trademark 10-17
10
10
