Design Guide | VLT® AutomationDrive FC 360
Table 60: Query (continued)
Field name Example (hex)
Number of registers HI 00
Number of registers LO 02
Byte count 04
Write data HI (Register 4: 1049) 00
Write data LO (Register 4: 1049) 00
Write data HI (Register 4: 1050) 02
Write data LO (Register 4: 1050) E2
Error check (CRC) –
Response
The normal response returns the follower address, function code, starting address, and quantity of registers preset.
Table 61: Response
Field name Example (hex)
Follower address 01
Function 10
Starting address HI 04
Starting address LO 19
Number of registers HI 00
Number of registers LO 02
Error check (CRC) –
9.11 Danfoss FC Control Profile
9.11.1 Control Word According to FC Profile (8-10 Protocol = FC Profile)
Speed ref.CTW
Master-follower
e30ba274.11
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Bit
no.:
Figure 61: Control Word According to FC Profile
Danfoss A/S © 2024.01 AJ435824192086en-000101 / 130R1295 | 113
