Danfoss VLT AutomationDrive FC 360 Design Guide

Design Guide | VLT® AutomationDrive FC 360
Maximum altitude above sea level without derating 1000 m (3281 ft)
Maximum altitude above sea level with derating 3000 m (9842 ft)
EMC standards EN 61800-3
Energy efficiency class
2)(2)
IE2
1) For more information on derating, see chapter Derating.
2) Determined according to EN 50598-2 at:
• . Rated load.
• . 90% rated frequency.
• . Switching frequency factory setting.
• . Switching pattern factory setting.
5.6 Cable Lengths and Cross-sections
Maximum motor cable length, shielded 150 m (492 ft)
Maximum motor cable length, unshielded 300 m (984 ft)
Maximum cross-section to motor and mains See chapter Electrical Data
Maximum cross-section to control terminals, rigid wire 1.5 mm
2
/16 AWG (2x0.75 mm
2
)
Maximum cross-section to control terminals, flexible cable 1 mm
2
/18 AWG
Maximum cross-section to control terminals, cable with enclosed
core
0.5 mm
2
/20 AWG
Minimum cross-section to control terminals 0.25 mm
2
/23 AWG
5.7 Digital Inputs
Programmable digital inputs 7
Terminal number 18, 19, 27, 29, 31, 32, 33
(1)
Logic PNP or NPN
Voltage level 0–24 V DC
Voltage level, logic 0 PNP < 5 V DC
Voltage level, logic 1 PNP > 10 V DC
Voltage level, logic 0 NPN > 19 V DC
Voltage level, logic 1 NPN < 14 V DC
Maximum voltage on input 28 V DC
Pulse frequency range 4 Hz–32 kHz
(Duty cycle) minimum pulse width 4.5 ms
Input resistance, Ri Approximately 4 kΩ
1) Terminals 27 and 29 can also be programmed as output.
All digital inputs are galvanically isolated from the supply voltage (PELV) and other high voltage terminals.
Danfoss A/S © 2024.01 AJ435824192086en-000101 / 130R1295 | 29
