5.6.2 Cable Routing
e30bu858.10
U, V, W
U/T1, V/T2, W/T3
Illustration 23: Cable Routing for Top Exit Cabinet to Drive Cabinet
AQ262139143212en-000301 / 130R0879 | 57Danfoss A/S © 2021.10
Electrical Installation
VLT® AutomationDrive FC 302
Operating Guide
