Danfoss VLT FC 103 Operating Instructions

3.3.3 Mechanical Dimensions
Enclosure type D1h D2h D3h D4h
110-160 kW
(380-480 V)
75-160 kW
(525-690 V)
200-315 kW
(380-480 V)
200-400 kW
(525-690 V)
110-160 kW
(380-480 V)
75-160 kW
(525-690 V)
200-315 kW
(380-480 V)
200-400 kW
(525-690 V)
IP
NEMA
21/54
Type 1/12
21/54
Type 1/12
20
Chassis
20
Chassis
Shipping dimensions
[mm]
Height 587 587 587 587
Width 997 1170 997 1170
Depth 460 535 460 535
Drive dimensions [mm]
Height 901 1107 909 1122
Width 325 420 250 350
Depth 378 378 375 375
Max weight [kg] 98 164 98 164
Table 3.3 Mechanical Dimensions, Enclosure Types D1h-D4h
Enclosure type D5h D6h D7h D8h E1 E2
110-160 kW
(380-480 V)
75-160 kW
(525-690 V)
110-160 kW
(380-480 V)
75-160 kW
(525-690 V)
200-315 kW
(380-480 V)
200-400 kW
(525-690 V)
200-315 kW
(380-480 V)
200-400 kW
(525-690 V)
355-450 kW
(380-480 V)
450-630 kW
(525-690 V)
355-450 kW
(380-480 V)
450-630 kW
(525-690 V)
IP
NEMA
21/54
Type 1/12
21/54
Type 1/12
21/54
Type 1/12
21/54
Type 1/12
21, 54
Type 12
00
Chassis
Shipping
dimensions [mm]
Height 660 660 660 660 840 831
Width 1820 1820 2470 2470 2197 1705
Depth 510 510 590 590 736 736
Drive
dimensions [mm]
Height 1324 1663 1978 2284 2000 1547
Width 325 325 420 420 600 585
Depth 381 381 386 406 494 498
Max weight [kg] 116 129 200 225 313 277
Table 3.4 Mechanical Dimensions, Enclosure Types D5h-D8h, E1-E2
Installation Operating Instructions
14 Danfoss A/S © Rev. 05/2014 All rights reserved. MG16J202
