11 Specifications
11.1 Power-dependent Specifications
N110 N132 N160 N200 N250 N315 P355 P400 P450
Normal Load* NO NO NO NO NO NO NO NO NO
Typical Shaft output at 400 V [kW] 110 132 160 200 250 315 355 400 450
Typical Shaft output at 460 V [hp] 150 200 250 300 350 450 500 550 600
Enclosure IP21 D1h D1h D1h D2h D2h D2h E1 E1 E1
Enclosure IP54 D1h D1h D1h D2h D2h D2h E1 E1 E1
Enclosure IP20 D3h D3h D3h D4h D4h D4h - - -
Enclosure IP00 - - - - - - E2 E2 E2
Output current
Continuous (at 400 V) [A] 212 260 315 395 480 588 658 745 800
Intermittent (60 s overload) (at 400 V)[A] 233 286 347 435 528 647 724 820 880
Continuous (at 460/480 V) [A] 190 240 302 361 443 535 590 678 730
Intermittent (60 s overload) (at 460/480 V)
[kVA]
209 264 332 397 487 588 649 746 803
Continuous kVA (at 400 V) [kVA] 147 180 218 274 333 407 456 516 554
Continuous kVA (at 460 V) [kVA] 151 191 241 288 353 426 470 540 582
Max. Input current
Continuous (at 400 V) [A] 204 251 304 381 463 567 647 733 787
Continuous (at 460/480 V) [A] 183 231 291 348 427 516 580 667 718
Max. external mains fuses [A] 315 350 400 550 630 800 900
Max. cable size
Max. cable size: mains, motor and load
share mm (AWG)]
2 x95 (2x3/0) 2x185 (2x350) 4x240 (4x500 mcm)
Max. cable size: brake mm (AWG)] 2 x95 (2x3/0) 2x185 (2x350) 2x185 (2x350 mcm)
Estimated power loss at 400 V [W] 2555 2949 3764 4109 5129 6663 7532 8677 9473
Estimated power loss at 460 V [W] 2257 2719 3612 3561 4558 5703 6724 7819 8527
Weight, enclosure IP21, IP54 kg (lbs.)
62 (135) 125 (275)
270
(594)
272
(598)
277
(609)
Weight, enclosure IP20 kg (lbs.) 62 (135) 125 (275) - - -
Weight, enclosure IP00 kg (lbs)
-
234
(515)
236
(519)
313
(689)
Efficiency 0.98
Output frequency [Hz] 0-590 Hz
Heat sink overtemp. trip [°C]
110
Power card ambient trip [°C]
75 85
*Normal overload=110% current for 60 s
Table 11.1 Mains Supply 3x380-480 V AC
