digit (left) of the parameter number indicating the
group number of the parameter in question.
• Using the [QUICK MENU] key, it is possible to get
access to the most important parameters of the
frequency converter. After programming, the fre-
quency converter is in most cases ready for
operation. Scroll through the Quick menu using
the [+ / -] keys and change the data values by
pressing [CHANGE DATA] + [OK].
• The Menu mode allows choosing and changing
all parameters as required. However, some pa-
rameters will be "shaded off", depending on the
choice in parameter 100 Configuration.
■ Quick menu with LCP 2 control unit
Start Quick Setup by pressing the [QUICK MENU]
key, which will bring out the following display values:
50.0 Hz
SETUP
1
QUICK MENU X OF Y
001 LANGUAGE
ENGLISH
At the bottom of the display, the parameter number
and name are given together with the status/value of
the first parameter under the Quick menu. The first
time the [QUICK MENU] key is pressed after the unit
has been switched on, the readouts always start in
pos. 1 - see table below.
Pos. Parameter no. Unit
1 001 Language
2 102 Motor power [kW]
3 103 Motor voltage [V]
4 104 Motor frequency [Hz]
5 105 Motor current [A]
6 106 Rated motor speed [rpm]
7 107 AMT
8 204 Minimum reference [Hz]
9 205 Maximum reference [Hz]
10 207 Ramp-up time [sec]
11 208 Ramp-down time [sec]
12 002 Local/remote operation
13 003 Local reference [Hz]
■ Parameter selection
Menu mode is started by pressing the [MENU] key,
which produces the following readout on the display:
50.0 Hz
FREQUENCY
0 KEYB.&DISPLAY
Line 3 on the display shows the parameter group
number and name.
In Menu mode, the parameters are divided into
groups. Selection of parameter group is effected us-
ing the [< >] keys.
The following parameter groups will be accessible:
Group no. Parameter group
0 Operation & Display
1 Load & Motor
2 References & Limits
3 Inputs & Outputs
4 Special functions
5 Serial communication
6 Technical functions
When the required parameter group has been se-
lected, each parameter can be chosen by means of
the [+ / -] keys:
FREQUENCY
001 LANGUAGE
ENGLISH
50.0 Hz
The 3rd line of the display shows the parameter
number and name, while the status/value of the se-
lected parameter is shown in line 4.
Changing data
Regardless of whether a parameter has been se-
lected under the Quick menu or the Menu mode, the
procedure for changing data will be the same.
Pressing the [CHANGE DATA] key gives access to
MG.04.A1.02 - VLT is a registered Danfoss trade mark
27
