Datalogic Magellan 2200VS User Manual

230 Magellan
®
2200VS/2200VS and 2300HS/2300HS
EAN-8 Minimum Segment Length
Specifies the minimum number of characters necessary in an EAN-8/
JAN-8 label segment in order for the scanner to accept a label for decod-
ing. Selectable from 5 to 15 characters.
To set this feature:
1. Scan the SWITCH bar code.
2. Scan the bar code representing the desired option below or on the
following pages. You’ll need to cover any unused bar codes on facing
pages to ensure that the scanner reads only the bar code you intend
to scan.
Complete the programming sequence by scanning the SWITCH bar
code.
EAN-8 MINIMUM SEGMENT LENGTH = 5 CHARACTERS
EAN-8 MINIMUM SEGMENT LENGTH = 6 CHARACTERS

Datalogic Magellan 2200VS Specifications

General

Decoding standards	-1D + GS1 DataBar, -GS1 DataBar Expanded Stacked, -GS1 DataBar Stacked, -GS1 DataBar Stacked Omnidirectional.
Standard interfaces	USB, RS-232
Dimensions (WxDxH)	152 x 152 x 97 mm
Product color	Gray
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	1100 g
